Art Pro Audio DualXDirect 2-Channel Active Direct Box Connects Unbalanced Instrument, Line, or Speaker Signals to Balanced Inputs

$79.99
SKU: DUALXDIRECT
Condition: New
Availability: Special Order - Usually Ships in 3-5 Days
Shipping: Calculated at Checkout
Adding to cart… The item has been added
Have more questions? Ask an Expert
Free shipping on orders over $200
30-Day Return Policy
Canadian Owned & Operated
Price Match Guarantee

Descriptions

About: Art Pro Audio DualXDirect 2-Channel Active Direct Box Connects Unbalanced Instrument, Line, or Speaker Signals to Balanced Inputs

The DualXDirect is a 2-channel active direct box for connecting unbalanced instrument, line, or speaker signals to balanced inputs.

Each input signal is sent to a transformer-isolated XLR output and a parallel Thru jack so it can simultaneously be connected to an amplifier on stage. Unique among ART DI boxes, XDirect models feature both 1/4" TRS and XLR inputs for expanded connectivity.

Front panel switches engage 30 dB of attenuation to accommodate high-level signals, and a ground lift to reduce hum.

The active circuitry can operate on phantom power or for over 100 hours on a new 9-volt battery. Active DIs are often a great match for sources like guitars and basses with passive pickups, or acoustic guitars with piezo pickups and no preamp.

Simple and durable, the DualXDirect is a compact DI in a rugged aluminum enclosure with two independent channels and a streamlined feature set.

Features:

  • 2 Independent Channels
  • 1/4" TRS / XLR Combo Inputs
  • 1/4" Thru Connectors
  • Balanced XLR Outputs
  • Switchable 30dB Attenuation and Ground Lift per Channel
  • Powered by 9-Volt Battery (100+ Hours) or Phantom Power

Specifications:

  • Active or Passive: Active
  • Inputs: 2x 1/4" TRS / XLR Combo Jacks
  • Outputs:
    • 2x XLR
    • 2x 1/4" TRS Thru
  • Input Impedance: 470 kΩ
  • Output Impedance: <600Ω
  • Maximum Input Level: +4 dBu above Attenuation Setting
  • Maximum Output Level:
    • +6 dBu (Battery)
    • +14 dBu (Phantom)
  • Controls Attenuator:
    • (0 dB, -30 dB)
    • Ground Lift (All per Chanel)
  • Frequency Response: 10 Hz - 100 kHz, +/- 0.5 dB @ 0 dBu
  • Dynamic Range: >100 dB (Typical)
  • Total Harmonic Distortion: <.05% (Typical)
  • Channel Separation: >80 dB (Typical)
  • Power Requirements:
    • 9V, 7.5 mA (Battery, Alkaline Recommended)
    • 18V - 48V, 6.5 mA (Phantom, per Channel)
  • Battery Life: 100+ Hours
  • Dimensions (HWD):
    • 1.85" x 4.6" x 3.9"
    • 4.7 cm x 11.7 cm x 9.9 cm
  • Weight: 0.84 lbs / 380 g
