About: AudioControl The Epicenter Digital Bass Restoration Processor - Mexico Edition

For nearly three decades, The Epicenter has been revolutionizing the world of music by delivering powerful and impactful bass to music lovers everywhere. Nowhere has The Epicenter made a greater impact than among fans of Mexican music and culture, who appreciate the authentic powerful bass The Epicenter brings to the mix.

To celebrate this deep connection to Mexican Heritage through music, we are proud to present The Epicenter Edición México. Featuring the iconic green, white and red of the flag of Mexico, and adorned with vintage-style native glyphs, The Epicenter Edición México stands outs with a vibrant illuminated tricolor logo.

This special edition retains the renowned sound quality and unmatched bass restoration that has made The Epicenter a staple in music enjoyment worldwide, now with a touch of Mexican flavor.

Features:

• AudioControl’s Original Digital Bass Restoration Circuit
• Balanced Differential Inputs
• ParaBASS® Controls for Bass Shaping
• Voltage Limiter for Gain Matching
• Programmable PFM Subsonic Filter Subwoofer Protection
• 13.5 Vrms Maximum Output Level
• Lighted Epicenter Logo Flashes with Music
• ACR-1 Dash Remote Included for Bass Restoration Control
• Screen Printed Mexican Flag and Native Glyphs
• Tricolor The Epicenter Illuminated Logo
• Certificate of Authenticity

Specifications:

Inputs

• Preamp Inputs: 2 (2 channels)
• Maximum Input Level: 15 Vrms
• Input Impedance: 10kΩ

Outputs

• Preamp Outputs: 2 (2 channels)
• Maximum Output Level: 13.5Vrms
• Output Impedance: 150Ω

Performance

• Total Harmonic Distortion: 0.003%
• Frequency Response: 10Hz-100kHz
• Signal to Noise: 130dB

Control

• Remote In

General

• Power Supply: High Headroom PWM Switching
• Current Draw: 150mA
• Recommended Fuse Rating: 1A

Weights & Dimensions

• Dimensions (W x D x H): 8″ x 5.5″ x 1.2″
• Weight: 1.8 lbs (0.8 kg)

What's in the Box:

• The Epicenter Edición México
• ACR-1 Remote
• Power Connector
• Certificate of Authenticity
• Quick Start Guide
• Warranty
