AudioControl The Epicenter Micro Bass Restoration Processor & Line Output Converter

$399.95

$359.95

Description
Shipping & Returns

Description

About: The Epicenter Micro - Bass Restoration Processor & Line Output Converter

The Epicenter Micro combines AudioControl's legendary digital bass restoration with world-renowned OEM integration capabilities. Featuring a speaker-level input stage with selectable impedance loads, as well as traditional line-level inputs, The Epicenter Micro brings out the best bass in any system, Trigger modes include traditional +12V remote in, GTO signal sense and audio sense. The PFM subsonic filter can be bypassed for the truly dedicated and the 10V+ output voltage setting beckons only the bravest among us. Use the included ACR-4 remote to independently adjust bass restoration and output level.

Features:

Patented Digital Bass Restoration
ParaBass Bass Shaping
Speaker and Line Level Inputs
Load Matching Circuit
Multiple Trigger Modes
ACR-4 Dual Knob Dash Mount Control Included

Inputs:

Speaker Level Input: 1 (2 channels)
Maximum Speaker Level Input: 40 Vrms / 400 W (20kΩ setting)
Speaker Level Input Impedance (selectable): 20Ω, 60Ω, 20kΩ
Line Level Input: 1 (2 channels)
Line Level Input Impedance: 7kΩ

Outputs:

Preamp Outputs: 1 (2 channels)
Maximum Output Level: 9.5Vrms/13V peak
Output Impedance: 150Ω

Performance:

Total Harmonic Distortion: 0.03%
Signal to Noise: >105 dB
Frequency Response: 10 Hz – 22 kHz ±1 dB

Control:

Remote In / GTO™ Signal Sense / Audio Sense
12VDC Remote Out (always active when unit is on)
