About: Axxess AXDSPX-HK4 DSP Data Interface with Amplifier Bypass Harness for Select 2013-2024 Hyundai/Kia Vehicles

Overcome the factory radio’s built-in “audio processing” with our patented digital signal processor, or “DSP”, vehicle-specific packages. Factory radios have built-in sound processing designed to make your mass-produced factory speakers sound as good as they can without breaking. This means that if you upgrade to aftermarket speakers, your factory radio will process the sound according to the factory settings and your system just won’t sound as great as you hoped it would. To remove the limitations of the factory radio and get clean signals for aftermarket audio gear, you will need a sound processor like our line of patented DSP products. Our DSP is unlike any other on the market offering not only serious sound improvements but retains many of the features commonly lost when upgrading a sound system.

Features:

• Retains ability to work with S/PDIF® digitally controlled amplified systems
• Package includes AXDSP-X interface, vehicle-specific T-harness, and an amplifier bypass harness
• Factory amplifier does not need to be retained
• Install location: At the factory amplifier
• Micro “B” USB updatable
• 1-year limited warranty

Specifications:

• Selectable 31-band Graphic EQ or 5-band parametric EQ on each channel with high pass, low pass, and bandpass filters
• 6 inputs and 10 individually assignable outputs
• Selectable slope (12, 24, 36, or 48db per octave)
• Selectable Graphic or Parametric EQ
• Independent equalization on each of the 10 outputs
• Each channel can be delayed independently up to 10 ms
• Clipping detection and limiting circuits
• Bass knob included
• Retains OE voice prompts (Blue Link®/UVO®) with adjustable level if vehicle is equipped
• Settings adjusted wirelessly in the free AX-DSP-XL app available for smartphones and tablets
• Read, write, and store configurations for future recall
• Password protect feature available in the app

Vehicle Applications:

HYUNDAI

• Elantra 2017-2020 , Amplified , Amplifier Location: Right Side Trunk.
• Elantra GT 2018-2020 , Amplified , Amplifier Location: Right Side Trunk.
• Kona 2018-2023 , Amplified , Amplifier Location: Below Passenger’s Seat.
• Santa Fe 2013-2023 , Amplified , Amplifier Location: Below Passenger’s Seat.

KIA

• Cadenza 2017-2020 , Amplified , Amplifier Location: Right Side of Trunk, Behind Trim Panel.
• Forte 2019-2023 , Amplified , Amplifier Location: Right Side of Trunk, Behind Trim Panel.
• Niro (EV) 2017-2021 , Navigation , Amplifier Location: Drivers Kick.
• Niro (Hybrid Electrical) 2018-2021 , Navigation , Amplifier Location: Center of Instrument Panel.
• Niro (Plug-In Hybrid) 2018-2021 , Navigation , Amplifier Location: Center of Instrument Panel.
• Optima 2016-2020 , Amplified , Amplifier Location: Right Side of Trunk, Behind Trim Panel.
• Sorento 2019-2020 , Amplified , Amplifier Location: Below Passenger’s Seat.
• Soul 2017-2023 , Amplified , Amplifier Location: Below Driver’s Seat.
• Soul EV 2020-2023 , Amplified , Amplifier Location: Center Console Towards Rear.
• Sportage 2017-2022 , Amplified , Amplifier Location: Right Rear Trunk Space, Behind Trim Panel.
• Telluride 2020-2024 , Amplified , Amplifier location: Below Passenger’s seat
