DB Drive G7 150.4 G7 Competition Class D 4-Channel Amplifier - 125W RMS x 4

Name: Singh Electronics
Address: 7003 Steeles Avenue West, Toronto, ON, M9W 0A2, CA
Telephone: +1 (416) 745-1021
Price range: $

$894.95

$814.95

SKU:: G7150.4
Condition:: New
Availability:: Special Order - Usually Ships in 2-3 Weeks
Shipping:: Calculated at Checkout

DB Drive G7 150.4 G7 Competition Class D 4-Channel Amplifier - 125W RMS x 4

$894.95

$814.95

Description
Shipping & Returns

Description

About: DB Drive G7 150.4 G7 Competition Class D 4-Channel Amplifier - 125W RMS x 4

Discover the future of sound with the G7 150.4 Class AB 4 Channel Amplifier! This powerhouse of audio innovation transforms your listening experience with cutting-edge features like ATC – Audiophile Grade Tiffany RCA Connectors and ACT – Adaptive Crossover Technology. Feel the pulse with high-efficiency Class D Technology and enjoy seamless integration with Direct Connect Speaker Terminals. With 4 Gauge Power Wire Inputs and APC – Audio Protection Circuit, your audio is not only powerful but protected. The SESI – Signal Evaluation Status Indicator and CHM – Collective Heat Management ensure optimal performance, while the Variable 12dB 3-Way Active Crossover offers unparalleled sound customization. With a frequency response of 20Hz to 30KHz and an impressive signal-to-noise ratio of <85dB, every note is crystal clear. Offering a rated power of 4 x 250 Watts at 2Ω and bridgeable to 2 x 500 Watts at 4Ω, the G7 150.4 is ready to redefine your audio landscape. Upgrade to the G7 AMPLIFIERS series and experience sound like never before – pure, powerful, and precise!

Features:

ATC – Audiophile Grade Tiffany RCA Connectors
ACT – Adaptive Crossover Technology
High efficiency Class D Technology
Direct Connect Speaker Terminals
4 Gauge Power Wire Inputs
APC – Audio Protection Circuit
SESI – Signal Evaluation Status Indicator
CHM – Collective Heat Management

Specifications:

Rated Power @14.4 Volts

4 x 125 Watts @ 4Ω
4 x 250 Watts @ 2Ω
2 x 500 Watts @ 4Ω Bridged

Working Voltage: 10 - 16 Volts
Frequency Response: 20Hz - 30KHz
Signal to Noise Ratio: <85dB
Damping Facto: 100dB<
Low Level Input: 6V - 0.2V
ACT - Variable Crossover HP/BP/LP
Ch 1/2 High Pass Filter Variable: 20Hz - 8KHz
Ch 1/2 Low Pass Filter Variable: 50Hz - 8KHZ
Ch 3/4 High Pass Filter Variable: 20Hz - 8Khz
Ch 3/4 Low Pass Filter Variable: 50Hz - 8KHz
Minimum Working Impedance: 2 Ohms
Dimensions

Length: 7.87"/ 200 mm
Width: 9.13"/ 232 mm
Height: 2.53"/ 64.5 mm
