DB Drive

DB Drive NEO-M2 NEO Mini Series 2-Channel Marine Amplifier - 125W RMS x 2

$329.95
$279.95
SKU:
NEO-M2
UPC:
810219028685
Condition:
New
Availability:
Special Order - Usually Ships in 4-8 Days
Shipping:
Calculated at Checkout

DB Drive NEO-M2 NEO Mini Series 2-Channel Marine Amplifier - 125W RMS x 2

$329.95
$279.95

About: DB Drive NEO-M2 NEO Mini Series 2-Channel Marine Amplifier - 125W RMS x 2

Product Highlights:

  • 2 Channel Class D Full Range Technology
  • 2Ω Stereo load Capability
  • Audiophile Grade Nickel Plated RCA connectors
  • Variable 12db High-Pass or Low-pass crossover filters
  • Bridgable outputs @ 4Ω load
  • Marine Grade Conformal Coated Double Sided PCB
  • Compatible with any 4/2Ω Loudspeaker

Specifications:

  • Rated Power @ 14.4 Volts:
    • 2 x 125 Watts @ 4Ω
    • 1 x 500 Watts @ 4Ω Bridged
    • 2 x 250 Watts @ 2Ω
  • THD (100Hz @ 1Ω): 0.04%
  • Bandwidth (-3 dB): 18Hz ~ 22KHz
  • Damping Factor (1KHz @ 4Ω): 100
  • S/N ratio (as weighted @ 1 Volt): 99db
  • Input Sensitivity: 0.20V ~ 6.0V RMS
  • Minimum Load Impedance: 2Ω
  • Low-Pass filter Range: 50Hz ~ 300Hz
  • Sub-Sonic filter Range: 15Hz ~ 300Hz
  • Dimensions (L x W x H): 6.10" x 4.13" x 1.92" (155 x 105 x 48 mm)
