About: DB Drive WDX M4 WDX Series 4-Channel Marine Amplifier - 150W RMS x 4

Introducing the DB Drive WDX M4: the ultimate 4 Channel IPX6 Rated Marine Amplifier that will take your sound experience to a whole new level. Get ready to be blown away by its impressive capabilities and features. With a power rating of 4 x 300 Watts at 2Ω and 4 x 150 Watts at 4Ω, this amplifier delivers crystal-clear, high-quality sound that will make your music come alive. The WDX M4 is equipped with IPX6 Marine grade conformal coated PCB, ensuring durability and protection against the elements. Its Adaptive Crossover Technology and Collective Heat Management guarantee optimal performance and prevent overheating. Plus, the Audio Protection Circuit and Bridgeable outputs at 4ohm load make it compatible with any 4/2 ohm loudspeaker. Whether you're on land or at sea, the DB Drive WDX M4 Marine Amplifier is the perfect companion for your audio system. Upgrade your sound today and let the music inspire your journey!

Features:

• 4 Channel full range class D technology
• IPX6 Marine grade conformal coated PCB
• ACT – Adaptive Crossover Technology
• CHM – Collective Heat Management
• APC – Audio Protection Circuit
• 2 ohm stereo load capability
• Bridgeable outputs @ 4ohm load
• Compatible with any 4/2 ohm loudspeaker

Specifications:

• Rated Power @ 14.4 Volts:
• 4 x 150 Watts @ 4Ω
• 4 x 300 Watts @ 2Ω
• 2 x 600 Watts @ 4Ω Bridged
• Frequency Response: 20Hz ~ 22Hz
• S/N Ratio: 103
• Damping factor: 200<
• Independent Selectable X-over: HPF / LPF /Ful
• Variable High/Low Pass Filter (Ch1/2): 40Hz ~ 300Hz
• Variable High/Low Pass Filter (Ch1/2): 40Hz ~ 300Hz
• Working Voltage: 12-15 Volts
• Dimensions (L x W x H): 10.13" x 5.25" x 2" (257.3 x 133.4 x 50.8 mm)
