About: DB Drive WDX1000.1 WDX Series Mini 1000W RMS Monoblock Car Amplifier

Unlock the true potential of your audio system with the DB Drive WDX1000.1 Class D Mono Amplifier. Designed with cutting-edge technology, this powerhouse amplifier delivers a staggering 1000W at 1Ω, ensuring that your sound is clear, crisp, and powerful. Its monoblock Class D internal circuitry ensures efficiency and reliability, while the direct connect speaker terminals and 4-gauge power wire input offer seamless connectivity. The adaptive crossover technology and variable subsonic filter (10Hz-40Hz) allow for precise sound tuning, making every note perfect. With collective heat management and an audio protection circuit, your amplifier stays cool and protected, ensuring longevity and peak performance. Whether you're a seasoned audiophile or just starting, the WDX1000.1 is your gateway to an unparalleled audio experience.

Features:

• Conformal PCB Coating
• CHM- Collective Heat Management
• ACT – Adaptive Crossover Technology
• APC – Audio Protection Circuit
• Full Range Class “D” Circuitry
• 4 Gauge

Specifications:

• Rated Power @ 14.4 Volts:
• 1 x 1000 Watts @ 1Ω
• 1 x 500 Watts @ 2Ω
• 1 x 250 Watts @ 4Ω
• Low Level Input: 6V – 0.2V
• Bass Boost: Variable 0 ~ 12dB
• Variable High Pass Filter (12dB Slope): 40Hz ~ 10Kz
• Variable Low Pass Filter (12dB Slope): 15Hz ~ 1Khz
• Minimum Working Impedance: 1 Ohm
• Working Voltage: 12-15 Volts
• Frequency Response: 20Hz ~ 300Hz
• S/N Ratio: < 95 dB
• Bass Equalizer: 0dB – 9dB
• Damping Factor: 100dB <
• Dimensions (L x W x H): 9" x 5.50" x 2.38" (228.6 x 139.8 x 60.5 mm)
