About: DS18 6XL650N-4 XL Series 6.5" 325W RMS Neodymium Rings Mid-Range Loudspeaker - 4 Ohm (Each)

DS18 presents the 6XL650N-4, a 6.5" Mid-Range Loudspeaker that will transcend the boundaries of ordinary audio. The 6XL650N-4 is not for the faint of heart. With its staggering RMS Power Handling of 325W and a MAX Power Handling of 650W, this speaker leads your soundstage with unparalleled strength. From the subtlest of melodies to the most thunderous basslines, the 6XL650N-4 handles it all with finesse, delivering every sonic nuance with precision. But it’s not just about power; the expert attention to detail is what sets the 6XL650N-4 apart. With a Sensitivity rating of 98.5dB, this speaker is finely tuned to capture the most delicate harmonies and unleash them with breathtaking clarity.

The secret behind the 6XL650N-4's exceptional performance lies in its Neodymium Rings. These rare-earth magnets, weighing 11.4 Oz, provide an unparalleled magnetic field strength, allowing for greater control and accuracy in reproducing sound. This means every sound is reproduced to captivate your senses and bring you that much closer to the music. The 6XL650N-4 not only delivers an extraordinary audio experience, but it also adds a touch of elegance to your car interior. The aluminum basket, dressed in a satin black finish, provides a sturdy foundation for the 6XL650N-4. Engineered with precision, this custom-tooled basket provides unparalleled stability, effectively reducing unwanted vibrations, and ensuring distortion-free sound reproduction. The strategic design incorporates ample ventilation, allowing for efficient heat dissipation, even during prolonged listening sessions at high volumes.

Superior audio performance demands pristine signal transmission, and DS18's polished high quality spring loaded push terminals deliver just that. The polished surface minimizes resistance and contact irregularities, effectively reducing signal loss and preserving the integrity of your audio signals. The spring-loaded mechanism further simplifies the installation process, making it easy to achieve a tight and secure connection every time. Experience the power, precision, and passion that only DS18 can deliver. Upgrade your car audio with DS18's 6XL650N-4 and unlock a realm of sonic ecstasy that will leave you breathless.

6.5" Mid-Range Loudspeaker With Neodymium Rings

The 6XL650N-4 was built for performing — pushing 325W RMS and 650W MAX with zero compromise on clarity or control in any venue.

Precision Meets Power

With a sensitivity of 98.5dB, this speaker delivers raw volume and crystal-clear detail that's noticeably smooth in any system.

Powered by Neodymium

Its built around an 11.4 oz neodymium ring magnet: offering sharper highs, tighter mids, and faster response — all while reducing weight in your setup.

Engineered for Performance

The custom aluminum basket offers top-tier stability, less flex, and less distortion: even at max volume. Its vented design keeps everything cool, so you can run LOUD without overheating.

Easy, Clean Install

Spring-loaded, polished terminals give you maximum conductivity with minimum hassle. Just press, connect, and get LOUD!

Product Highlights:

• 6.5" Mid-Range
• MAX Power: 650 Watts
• RMS Power: 325 Watts
• Impedance: 4-Ohm
• Neodymium Magnet
• Aluminum Basket

Specifications:

• Nominal Diameter: 6.5" (165 mm)
• Nominal Impedance: 4 Ohms
• RMS Power Handling: 325 Watts
• MAX Power Handling: 650 Watts
• Sensitivity (1w/1m): 98.5dB
• Frequency Response: 60Hz-12.5KHz
• Recommended Hi Pass Crossover: 100Hz
• Sold as Pair or Single: Single

Motor:

• Voice Coil Diameter: 2" (50.8 mm)
• Voice Coil Former Material: Kapton
• Winding Material: CCAW
• Cone Material: Non-pressed Paper
• Dust Cap Material: Paper
• Surround Material: Cloth
• Basket Material: Aluminum
• Basket Color/Finish: Satin Black
• Magnet Material: Neodymium
• Magnet Weight: 11.4 Oz
• Displacement Volume: 0.34L / 0.012ft3

Thiele & Small Parameters:

• Equivalent Volume (Vas): 5.86L / 0.206ft3
• Excursion (one way) (Xmax): 3.7 mm
• Free Air Resonance (Fs): 100Hz
• Mechanical Factor (Qms): 4.385
• Electrical Factor (Qes): 0.256
• Total Factor (Qts): 0.242
• Mechanical Mass (Mms): 11.278
• Mechanical Compliance (Cms): 0.214 mm/N
• BL Factor (BL): 9.449
• Voice Coil Inductance (Le): 0.1744 mH
• Cone Area (Sd): 136.85 cm²
• DC Resistance (Re): 3.2 ohm
• Mechanical Mass w/o air (Mmd): 11.278 g

Measurements:

• Overall Diameter: 6.7" (170 mm)
• Overall Depth: 3.19" (81 mm)
• Front Mount Baffle Cutout: 5.9" (150 mm)
• Mounting Depth: 2.83" (72 mm)
• Motor Diameter: 4.13" (105 mm)
