Descriptions

About: DS18 G6.5XC GEN-X 6.5" 50W RMS 2-Way Component Set Speaker System

Get ready to experience power, clarity, and range like never before! The legendary GEN-X Coaxial Series is back and stronger than ever with the G6.5XC 2-Way Component Set, delivering an upgraded level of performance that will blow your mind. This set includes a powerful 6.5-inch woofer and a high-quality silk dome tweeter, as well as a 2-way passive crossover to ensure clear and crisp sound. The 6.5-inch woofer delivers power, precision, and punch to your music. The paper cone provides a natural, warm sound, while the rubber surround allows for tight, controlled bass response. This woofer is an essential component for any audiophile who demands uncompromising sound quality.

The silk dome tweeter has a 1-inch voice coil diameter and neodymium magnet material, which help it produce clear and detailed high frequencies. The 2-way passive crossover has a frequency crossover point of 3.5KHz and a 12dB/Oct cut-off slope, ensuring that the woofer and tweeter work together seamlessly. The GEN-X series was made for amplifiers, but can be used in factory settings with 4-ohm factory amplifiers in most cases for great sound and clarity over factory OEM speakers. This powerful and durable set will bring your music to life with a wide range of frequencies and clear sound. Don’t settle – get the G6.5XC Component Set and experience music like never before.

Product Highlights:

• 6.5" 2-Way Component
• MAX Power: 150 Watts
• RMS Power: 50 Watts
• Impedance: 4 Ohm ~ 86db
• Barium Ferrite & Neodymium Magnets
• Pair ~ Crossovers & Grills Included

Specifications:

• Nominal Diameter: 6.5" (165mm)
• Nominal Impedance: 4 Ohm
• RMS Power Handling: 50 Watts
• MAX Power Handling: 150 Watts
• Sensitivity (1w/1m): 86dB
• Frequency Response: 35Hz-20KHz
• Recommended HI Pass Crossover: 60HZ
• Number of Ways: 2
• Pair or Single: Pair
• Grill Included: Yes

Motor:

• Voice Coil Diameter: 1" (25.5mm)
• Voice Coil Former Material: ASV
• Winding Material: EISV
• Cone Material: Paper
• Surround Material: Rubber
• Basket Material: Steel
• Basket Color: Black Matte
• Magnet Material: Barium Ferrite
• Magnet Weight: 9.87oz (280g)

Tweeter:

• Voice Coil Diameter: 1" (25.5mm)
• VC Former Material: ASV
• Winding Material: EISVM
• Diaphragm Material: Silk
• Magnet Material: Neodymium
• Magnet Weight: 8.7g

Thiele & Small Parameters:

• Equivalent Volume (Vas): 9.47L (0.33 ft3)
• Excursion (one way) (Xmax): 2.7mm
• Free Air Resonance(Fs): 72Hz
• Mechanical Factor (Qms): 4.5
• Electrical Factor (Qes): 1.47
• Total Factor (Qts): 1.1
• Mechanical Mass (Mms): 13.8g
• Mechanical Compliance (Cms): 345mm/N
• BL Factor (BL): 4
• Voice Coil Inductance (Le): 172uH
• Cone Area (Sd): 136.8cm2
• DC Resistance (Re): 3.7 Ohms
• Mechanical Mass w/o air (Mmd): 12g

Woofer Measurements:

• Overall Diameter: 6.5" (165.5mm)
• Overall Depth: 2.52" (64mm)
• Overall Diameter with Grill: 7" (179mm)
• Overall Depth with Grill: 3" (76mm)
• Front Mount Baffle Cutout: 5.6" (142mm)
• Mounting Depth: 2.24" (57mm)
• Motor Diameter: 3.15" (80mm)

Tweeter Measurements:

• Overall Diameter: 1.7" (43.5mm)
• Overall Depth: 1" (27mm)
• Front Mount Baffle Cutout: 1.6" (40.8mm)
• Mounting Depth: 0.57" (14.5mm)

Crossover Specifications:

• Passive Crossover Ways: 2 (Woofer / Tweeter)
• Frequency Crossover Point: 3.5KHz
• Power Handling: 400W
• Cut-Off Slope: 12dB/Oct
• Capacitor Type: Metal Film
• Coil Type: Inductor
• Terminal Type: Screw
• Housing Material: ABS

Crossover Measurements:

• Overall Length: 2.55" (65mm)
• Overall Depth: 4.7" (120mm)
• Overall Height: 1" (27.5mm)
