About: DS18 PRO-84XA 8” 10th Anniversary Mid-Bass Loudspeaker 275W RMS - 4 Ohms

Welcome to the world of DS18, where for 10 years we have been known to provide the loudest and cleanest sound on the streets. As we celebrate our 10th anniversary, we bring you the PRO-84XA, a mid-bass loudspeaker that is designed to deliver an unforgettable listening experience. The DS18 PRO-84XA is a 8-inch mid-bass speaker perfect for anyone who loves it loud, just like us! With a sensitivity rating of 97.8dB, these speakers can take your sound system to new levels of volume that you never thought were possible.

In classic DS18 fashion, the PRO-84XA features a steel basket with special 10^th Anniversary engraving and ferrite magnet, which is sure to evoke nostalgia and create new memories for some of our oldest customers. But that’s not all, the PRO-84XA can handle an RMS power of up to 275W and a maximum power of 550W. The frequency response range of 60Hz-8KHz means that the PRO-84XA can reproduce a wide range of frequencies, from lower bass tones to higher treble tones. The combination of a wide frequency response range and a recommended HI Pass Crossover of 80Hz makes the PRO-84XA a versatile mid-bass loudspeaker that can enhance the overall listening experience and deliver powerful and accurate sound.

At DS18, we are proud to have over ten years of experience in creating high-quality and powerful speakers. This experience has allowed us to create a signature sound that everyone knows and loves, and the PRO-84XA is no exception. Get yours today and experience the DS18 difference!

Product Highlights:

• 8" Mid-Bass
• MAX Power: 550 Watts
• RMS Power: 275 Watts
• Impedance: 4-Ohm
• Ferrite Magnet
• Anniversary Edition

Specifications:

• Nominal Diameter: 8" / 203mm
• Nominal Impedance: 4 Ohms
• RMS Power Handing: 275W
• Maximum Power Handing: 550W
• Sensitivity (1w/1m): 97.8dB
• Frequency Response: 60Hz-8KHz
• Recommended Hi Pass Crossover: 80Hz
• Voice Coil Diameter: 1.5" / 38mm
• Voice Coil Former Material: Kapton
• Winding Material: CCAW
• Basket Material: Steel
• Magnet Weight: 33oz

Thiele & Small Parameters:

• Vas: 18.37L / 0.64ft3
• Xmax: 2.5mm
• Fs: 82Hz
• Qms: 10.34
• Qes: 0.63
• Qts: 0.6
• Re: 3.82ohms

Measurements:

• Overall Diameter: 8.25" / 209.8mm
• Front Mount Baffle Cutout: 7.25" / 184mm
• Mounting Depth: 3.2" / 82mm
• Overall Depth: 3.45" / 88mm
• Product Weight: 5 lbs
• Product Dimensions: 9" x 9" x 4.25"
