Descriptions

About: DS18 PRO-DR1PK44 1" Driver + Horn Kit - 8 Ohm

Engineered to perfection and fine-tuned for maximum performance and ear-shattering loudness, the PRO-DR1PK44 is here to revolutionize your car audio system. Crafted from premium materials, the PRO-DR1PK44 exemplifies excellence in every aspect. With its cutting-edge design, the PRO-DR1PK44 is a force to be reckoned with. Featuring a formidable 1" 8-ohm CCA voice coil, this beast absorbs a staggering 240W of peak power, making it a true powerhouse that sets new standards for efficiency. The phenolic diaphragm guarantees exceptional clarity and precision, ensuring that no musical detail escapes your discerning ears.

The PRO-DR1PK44 boasts a distinctive square-shaped screw-on throat, a testament to its versatility and commitment to unrivaled acoustics. This unique design not only enhances the overall audio experience but also elevates decibel levels to previously unimaginable heights. With an astonishing sensitivity of 107.3 dB, this driver has the potential to reach mind-bendingly loud volumes. From the thunderous rumble of 800 Hz to the crystal-clear brilliance of a cymbal crash at 20 KHz, every nuance and detail of your music will come to life, capturing your senses, and transporting you to the heart of the performance.

But the PRO-DR1PK44 is not just about power and performance; it's designed to seamlessly integrate into your existing audio setup, complementing and enhancing your entire system. With its compact mounting depth of only 4.56 inches, these drivers offer extreme versatility, ensuring a hassle-free installation process. With its versatile design, convenient features, and meticulous craftsmanship, this driver is the ultimate choice for car audio enthusiasts who demand nothing but the best.

Product Highlights:

• Compression Driver with Horn
• 1 X PRO-DR1P
• 1 X PRO-H44/BK
• RMS Power: 120 Watts(240 Watts Peak)
• Impedance: 8  Ohm ~ 107.3dB
• Ferrite Magnet

Features:

• Nominal Impedance: 8 Ohm
• AES Power handling: 60W
• Program Power Handling: 120W
• Peak Power handling: 240W
• Sensitivity (1w/1m) With Horn: 107.3dB
• Frequency Response: 800Hz - 20Khz
• Recommended Hi Pass Crossover: 1KHz


Motor:

• Voice Coil Diameter: 1" / 25.4mm
• Voice Coil Former Material: Kapton
• Winding Material: CCA
• Diaphragm Material: Phenolic
• Magnet Material: Ferrite
• Magnet Weight: 0.38 Oz / 11g
• Body Material: Aluminum + ABS


Horn Specifications:

• Nominal Diameter: 4.5" / 115mm
• Throat Diameter: 1" / 25.4mm
• Sound Coverage: 45 x 45 (square)
• Body Material: ABS/PC Injected
• Color/Finish: Black

Measurements:

• Overall Diameter: 4.52" / 115mm
• Overall Depth: 4.88" / 124mm
• Mounting Depth: 4.5" / 116mm
• Mounting Hole Diameter: 3.26 x 3.26" / 83 x 83mm
• Bolt Pattern (Horn): 4 x 5.5mm / 100.5mm
• Gross Single Unit Weight: 2
• Single Unit Box Dimensions (W x L x H): 4.75" x 4.75" x 5.75"
