Descriptions

About: DS18 PRO-FR69NEO 6x9" Neodymium Full-Range Bullet Loudspeaker 250W RMS - 4 Ohm (Each)

Unleash the power of your music with the DS18 PRO-FR69NEO – a 6x9" neodymium full-range loudspeaker that is guaranteed to bring your music to life! With a staggering 500 watts of maximum power, this speaker delivers unparalleled volume and clarity that will transport you to a new dimension of sound.

The PRO-FR69NEO's high-powered neodymium magnet generates a much greater action force in the voice coil, providing a higher magnetic flux density in the air gap. As the strongest permanent magnet of all commercially available speakers, neodymium magnets are the perfect choice for those seeking simple perfection in sound. Designed with DS18's signature attention to detail, the PRO-F69NEO boasts a beautiful, tooled aluminum brushed accented basket and high-quality terminals that complement its sleek and modern design.

Additionally, the Silver Bullet Tweeter integrated in this speaker’s design widens the higher range of frequencies it reproduces bringing you a fuller range of frequencies to blast. With a frequency response of 100Hz – 9KHz, an impedance of 4 Ohms, and a sensitivity of 98 dB, the PRO-FR69NEO provides crystal-clear audio with no distortion. Its cloth edge surround, aluminum frame, and non-pressed paper cone ensure the highest quality materials for the best possible sound. Don’t settle for less, get the best with the PRO-FR69NEO.

Product Highlights:

• 6X9" Full-Range W/Bullet
• MAX Power: 500 Watts
• RMS Power: 250 Watts
• Impedance: 4-Ohm
• Neodymium Magnet
• 98dB ~ w/Grill

Specifications:

• Nominal Diameter 6×9″
• Nominal Impedance 4 ohms
• RMS Power Handling 250w
• MAX Power Handling 500w
• Sensitivity (1w/1m) 98dB
• Frequency Response 100Hz-9KHz
• Recommended HI Pass Crossover 120Hz
• Voice Coil Diameter: 1.5″ (38.6 mm)
• Voice Coil Former Material Kapton
• Winding Material CCAW
• Cone Material Paper
• Bullet Material Aluminum
• Magnet Weight 2.8 Oz
• Sold Individually

Thiele & Small Parameters:

• Equivalent Volume (Vas): 17.94Ltr
• Excursion (one way) (Xmax): 6.7mm
• Free Air Resonance (Fs): 109.95
• Mechanical Factor (Qms): 7.471
• Electrical Factor (Qes): 0.297
• Total Factor (Qts): 0.286
• DC Resistance (Re): 3.4 ohm

Measurements:

• Overall Diameter 6.57″ x 9.44" (167 x 240 mm)
• Front Mount Baffle Cutout 5.97" x 8.74" (152 x 222 mm)
• Mounting Depth 2.874″ (73 mm)
• Overall Depth 3.31″ (84 mm)
• Motor Diameter 4.13″
• Product Weight: 4.5 lbs
• Product Dimensions: 10.75" x 8" x 5"
