As a rider, you know the open-air environment comes with a set of challenges for your motorcycle’s audio system: but, the team of engineers at DS18 has crafted a solution that will take your motorcycle’s audio to new heights: introducing DS18’s PRO-SM69.2. Crafted with meticulous attention to detail, the PRO-SM69.2 features premium materials that contribute to its exceptional performance. The PRO-SM69.2 boasts a water-resistant cone, ensuring that rain or water splashes won't dampen your audio experience. The cloth edge surround enhances sound accuracy and durability, while the red steel basket provides a sturdy foundation for optimal sound reproduction. The non-pressed water-resistant paper cone guarantees excellent audio clarity and resilience, even in challenging conditions. The 1.5" voice coil size and 33 oz magnet further contribute to the speaker's impressive performance, ensuring every note is delivered with precision and power.

With power handling capability of 500W MAX, the PRO-SM69.2 delivers thunderous sound that will captivate your senses. Its 2-ohm single voice coil allows you to maximize your amplifier's power level at the lowest resistance, eliminating the need for bridging. Experience audio at its peak, even when cruising at 60 miles per hour down the highway. The PRO-SM69.2 ensures your music cuts through the wind and engine noise, providing a full and rich sound that will keep you energized throughout your journey.Installing the PRO-SM69.2 is a breeze, thanks to its manageable mounting depth of 2.68" and a front mount baffle cut-out dimension of 8.6x6". Within minutes, you'll have these powerful speakers seamlessly integrated into your motorcycle, ready to transform your audio experience. DS18’s PRO-SM69.2 is the ultimate audio upgrade for motorcycle enthusiasts who demand nothing but the best.

Specifications:

• Nominal Diameter: 6×9”
• Nominal Impedance: 2 Ohms
• RMS Power Handling: 250W
• MAX Power Handling: 500W
• Sensitivity (1w/1m): 96dB
• Frequency Response: 60Hz-5KHz
• Recommended HI Pass Crossover: 120Hz
• Sold Individually

Motor:

• Voice Coil Diameter: 1.5″
• Voice Coil Former Material: Kapton
• Winding Material: CCAW
• Cone Material: Water Resistant Paper
• Dust Cap Material: Water Resistant Paper
• Surround Material: Coated Cloth
• Basket Material: Steel
• Magnet Material: Ferrite
• Magnet Weight: 33 Oz

Thiele & Small Parameters:

• Equivalent Volume (Vas): 10.147 L
• Excursion (one way) (Xmax): 6.7 mm
• Free Air Resonance (Fs): 110 Hz
• Mechanical Factor (Qms): 7.358
• Electrical Factor (Qes): 0.959
• Total Factor (Qts): 0.848
• DC Resistance (Re): 2 ohm

Measurements:

• Overall Diameter 9.25 x 6.56″ (235 x 167 mm)
• Overall Depth 2.91″ (74 mm)
• Front Mount Baffle Cutout: 8.6 x 6" (220 x 152 mm)
• Mounting Depth: 2.68" (68 mm)
• Motor Diameter: 4.72" (120 mm)
• Product Weight: 5.5 lbs
• Product Dimensions: 10" x 7.25" x 4"
