Descriptions

About: DS18 PRO-TW820 2.3" 100W RMS High Compression Neodymium Super Bullet Tweeter - 4 Ohm (Each)

Discover the extraordinary power and precision of DS18's PRO-TW820! When it comes to power, the PRO-TW820 is a true force to be reckoned with. Don't be deceived by its compact size; this super tweeter packs an astonishing punch that will leave you in awe. With 200W of peak power handling, it effortlessly outperforms any other tweeter in its class. The sound produced is so rich, clear, and undeniably loud that it will redefine your sound system.

The PRO-TW820's motor is a true engineering marvel. It boasts a 1.4" voice coil diameter, ensuring optimal performance and efficiency. The diaphragm material is titanium, which produces a clear and vibrant sound, while the neodymium magnet provides unparalleled magnetism and stability. The body of the tweeter is crafted from aluminum, ensuring both lightweight design and robust construction. And the bullet, made from CNC aluminum, adds a touch of elegance and sophistication to the overall design.

One of the standout features of the PRO-TW820 is its adjustable mounting depth. With the supplied rings, you can easily modify the mounting depth to fit your specific needs. This flexibility ensures a seamless integration into your existing sound system, allowing for effortless customization. But what truly sets the PRO-TW820 apart is its durability and ease of maintenance. Should you ever find yourself pushing these tweeters to their limits, fear not. They are designed to withstand the most demanding conditions. And should the need arise, they can be disassembled and repaired on the spot in just 60 seconds. Your music will never be interrupted for long, allowing you to keep the rhythm alive and the party going.

Product Highlights:

• 2.3" High Compression Super Bullet Tweeter
• MAX Power: 200 Watts
• RMS Power: 100 Watts
• Neodymium Magnet
• Adjustable Surface Mount / Single
• Easily Repaired With The PRO-TW820VC

Specifications:

• Nominal Diameter: 2.3"
• Nominal Impedance: 4 Ohm
• AES Power Handling: 50W
• Program Power Handling: 100W
• Peak Power Handling: 200W
• Sensitivity (1w/1m): 105dB
• Frequency Response: 2Khz-20Khz
• Recommended Hi Pass Crossover: 3KHz
• Sold Individually

Motor Specifications:

• Voice Coil Diameter: 1" (25.4 mm)
• Voice Coil Former Material: KAPTON
• Winding Material: CCA
• Diaphragm Material: Aluminum
• Magnet Material: Neodymium
• Body Material: Aluminum

Measurements:

• Overall Diameter: 2.28" (58 mm)
• Overall Depth: 2.67" (68 mm)
• Front Mount Baffle Cutout: 1.69" (43 mm)
• Mounting Depth: 1.65-2.55" (42-65 mm)
• Gross Single Unit Weight: 1.5 lb
• Single Unit Box Dimensions (W x L x H): 3.25" x 2.75" x 3"
