DS18

DS18 ZXI-3542 3.5” 40W RMS 2-Way Full-Range Coaxial Speaker

$83.99
$73.99
SKU:
ZXI-3542
Condition:
New
Availability:
Sold Out
Shipping:
Calculated at Checkout
Out of stock

DS18 ZXI-3542 3.5” 40W RMS 2-Way Full-Range Coaxial Speaker

$83.99
$73.99

Out of stock

About: DS18 ZXI-3542 3.5” 40W RMS 2-Way Full-Range Coaxial Speaker (Pair)

Upgrade your car’s audio with DS18’s ZXI-3542, a powerful 2-ohm 3.5-inch coaxial speaker designed for crystal-clear sound and effortless installation. This compact yet high-performance speaker delivers rich, balanced audio that will transform any custom setup.

Built for superior sound quality, the glass fiber woofer cone produces clear, natural mids, while the 1” neodymium tweeter ensures crisp, high-frequency details. With 40W RMS and 120W Max power handling, the ZXI-3542 delivers distortion-free, dynamic audio, making your music sound fuller and more vibrant.

Designed for seamless fitment, this speaker easily replaces most OEM factory-installed speakers, eliminating the hassle of complex modifications. The barium ferrite magnet enhances bass response, while the rubber surround and steel basket add durability and vibration control, ensuring long-lasting performance even in demanding conditions.

Perfect for car audio enthusiasts looking for a quick, high-quality upgrade, the DS18 ZXI-3542 combines cutting-edge design with powerful acoustics. Elevate your in-car listening experience with a speaker that delivers both clarity and durability—because your music deserves the best. Upgrade today and feel the #DS18Difference.

Product Highlights:

  • 3.5" 2-Way Coaxial
  • MAX Power: 120 Watts
  • RMS Power: 40 Watts
  • Impedance: 4 Ohm
  • Barium Ferrite & Neodymium Magnets
  • Pair ~ 87dB

Specifications:

  • Nominal Diameter: 3.5" (89 mm)
  • Nominal Impedance: 4 Ohm
  • RMS Power Handling: 40W
  • MAX Power Handling: 120W
  • Sensitivity (1w/1m): 87dB
  • Frequency Response: 80Hz-20kHz
  • Recommended HI Pass Crossover: 120Hz
  • Number of Ways: 2-Way
  • Sold in Pair or Single: Pair
  • Grill Included: No
Woofer Specifications:
  • Voice Coil Diameter: 0.8" (20.4 mm)
  • Voice Coil Former Material: ASV
  • Winding Material: EISV
  • Cone Material: Glass fiber
  • Surround Material: Rubber
  • Basket Material: Steel
  • Basket Color/Finish: Black
  • Magnet Material: Barium Ferrite
  • Magnet Weight: 172g
Thiele & Small Parameters
  • Equivalent Volume (Vas): 2.4L / 0.0849ft3
  • Excursion (one way) (Xmax): 1.2mm
  • Free Air Resonance (Fs): 106Hz
  • Mechanical Factor (Qms): 4.39
  • Electrical Factor (Qes): 1.034
  • Total Factor (Qts): 0.836
  • Mechanical Mass (Mms): 3.8g
  • Mechanical Compliance (Cms): 1.225mm/N
  • BL Factor (BL): 3.4
  • Voice Coil Inductance (Le): 105.5uH
  • Cone Area 9Sd): 38cm2
  • DC Resistance (Re): 3.7 ohm
  • Mechanical Mass w/o air (Mmd): 2.6g
Tweeter Specifications:
  • Nominal Diameter: 1" (25.4 mm)
  • Voice Coil Diameter: 0.52" (13 mm)
  • Voice Coil Former Material: KSV
  • Winding Material: CCAW
  • Diaphragm Material: PEI
  • Magnet Material: Neodymium
  • Magnet Weight: 1.8g
Speaker Measurement:
  • Overall Diameter (Without Grill): 3.44" (87.3 mm)
  • Overall Depth (Without Grill): 2.21" (56.2 mm)
  • Front Mount Baffle Cutout: 3" (77 mm)
  • Mounting Depth: 1.74" (44.3 mm)
  • Motor Diameter: 2.56" (65 mm)
  • Gross Single Unit Weight: 0.387KG
  • Single Unit Box Dimensions (W x L x H): 240 x 120 x 70 mm
