Descriptions

About: Hertz DPower1D 300W RMS Monoblock Amplifier

Excellent for OEM systems upgrade, the Hertz DPower1 mono car audio amplifiers is an ultra-compact to ensure effortless installations in the increasingly narrow spaces of modern vehicles or in the factory amp area. The efficient D Class circuitdelivers 600 W of maximum power within a compact chassis, an essential requirement for in-car integration. The bass boost function enhances 45 Hz up to 12 dB to increase subwoofer punch. The double SPEAKER & RCA INPUTS allows the DPower1 to connect to any type of source, be it OEM or aftermarket. For an excellent integration with OEM systems DPower1 is equipped with a smart automated turn on and off circuit according to the factory radio.

Features:

• Ultra Compact - Excellent for OEM systems upgrade, the DPower amplifiers are ultra-compact to ensure effortless installations in the increasingly narrow spaces of modern vehicles or in the factory amp area.
• High Power/Size Ratio - The efficient D class circuit delivers 600 W of maximum power within a compact chassis, an essential requirement for in-car integration.
• Versatile X-Over - DPower1 bass boost function enhances 45 Hz up to 12 dB to increase subwoofer punch.
• Speaker & RCA Inputs - The double SPEAKER & RCA INPUTS allows the DPower amplifiers to connect to any type of source, be it OEM or aftermarket.
• Art Auto Turn-On/Off - For an excellent integration with OEM systems the DPower amplifiers are equipped with a smart automated turn on and off circuit according to the factory radio.

Specifications:

• Channels: 1
• Power supply voltage / fuse: 11 ÷ 15 VDC / 1 x 20 A
• Idling current (power ON/OFF)1 A / 0.04 mA
• Consumption @ 2Ω, 14.4 VDC (Max Musical Power):20 A
• Remote In: 4 ÷ 15 VDC - 1 mA
• ART™: Automatic Remote Turn-On/Off
• Distortion - THD (100 Hz @ 4Ω): 0.1 %
• Bandwidth (-3 dB): 10 ÷ 500 Hz
• S/N Ratio (A weighted @ 1 V): 105 dB
• Damping factor (100 Hz @ 4Ω): 100
• Pre-In sensitivity:
• LO: 0.2 ÷ 5 V
• HI: 0.8 ÷ 20 V
• Load impedance (MIN): 2Ω
• Max size: 8.75" x 6.3" x 1.99" (222.2 x 160 x 50.5 mm)
• Weight: 3.54lb (1.61 kg)
• Adjustable Crossovers: Yes

Output Power:

• Output Power (RMS) @ 14.4 VDC, THD 1%:
• 150 W x 1 (4Ω)
• 250 W x 1 (2Ω)
• Output Power (RMS) @ 14.4 VDC, THD 10%:
• 180 W x 1 (4Ω)
• 300 W x 1 (2Ω)
• Total Power: 300 W

Inputs/Filters:

• Inputs:PRE IN / SPEAKER IN
• Pre out FULL range: Yes
• Filters FULL: Yes
• Lo-Pass: 50 ÷ 220 Hz @ 12 dB/Oct
• Boost: 45 Hz: 0 ÷ 12 dB
• Remote Volume Control: (optional): (-20 ÷ 6) dB
