800 watt Hifonics ALPHA series compact four channel Super D-Class® car audio amplifier with electronic crossovers utilizing Ultra-Fi MOSFETS for high power and effiencey cooling with minimal distortion.
Features:
- Hifonics A800.1D
- Alpha Series Class-D Compact 800 Watt 1-Ohm Stable Monoblock Car Audio Amplifier
- Max Power Rating:
- 4 Ohms: 100 Watts x 4 chan.
- 2 Ohms: 200 Watts x 4 chan.
- 4 Ohms Bridged : 400 Watts x 2 chan.
- Total power output: 800 Watts
- Pulse Width Modulated MOSFET power supply
- Wired remote bass level control included
- LED power (green) and protect (red) indicators
- Accu-Cross crossovers allow for complete control of the signal directing to all speakers
- Flexible installation allows this amplifier to run in four channel or bridged 2-Channel mode
- Preamp RCA outputs to daisy chain multiple amps
- 3-way protection circuitry (thermal, overload, and speaker short protection)
- Heavy duty aluminum alloy heat-sink
- The Ultra-Fi™ MOSFET is designed for music production vs just electronics output power. It produces very musical high power with high efficiency for cooling and minimal distortion
- Frequency Response: 10 - 250 Hz
- Total Harmonic Distortion (THD): <0.05%
- Signal to Noise Ratio: >85 dB
- Crossovers (Switched Input Mode):
- 4CH / 2CH: DUPE / FULL / HPF
- Bandpass: LPF / FULL / HPF
- Variable high-pass crossover: 20Hz - 4kHz (DUPE MODE: 10Hz - 4kHz)
- Variable low-pass crossover (DUPE MODE): 50 - 4 kHz, 12 dB/octave
- Bass Boost: 0-12dB @ 45Hz
- Fusing: Use External Fuse
- Power Terminal 12V/GND: 8 AWG, 24 AWG
- Dimensions: 13.62"W x 5.75"D x 2.37"H
