About: iDatalink Maestro APX-S8-FO2 APX 8" Radio Installation Kit for Select Ford, Lincoln and Mercury Vehicles

APX 8" radio installation kit for select older Ford, Lincoln and Mercury vehicles.

Specifications:

• Allows you to install a Kenwood or JVC Direct Replacement radio with an 8" screen or 10.1" floating screen in select 2009-14 Ford, Lincoln, and Mercury vehicles with factory navigation (also requires the Maestro RR or RR2 module)
• Retains appearance of factory dash
• Retains the following factory features (if present):
• Factory amplifier with turn-on, fader, gain, DSP control, and speed-compensated volume
• Steering wheel audio controls with two function buttons and expandable radio functions
• Backup camera with dynamic parking guidelines and park assist chimes
• Factory 360° camera (if equipped)
• Secondary vehicle display (if factory equipped)
• Factory climate display/controls and vehicle settings from head unit's screen
• USB port
• Warning chimes
• Adds these features:
• Display vehicle information
• Selectable performance gauges including "Track Pack" gauges
• Read/reset check engine codes
• Provides 12V/15A accessory power and illumination output
• Provides outputs (parking brake, reverse, vehicle speed sensor [VSS]) needed to install a navigation or multimedia receiver

Compatible Radios:

• JVC KW-Z800AW
• JVC KW-Z1000AW
• Kenwood DAX8000S
• Kenwood Excelon DAX800XR
• Kenwood Excelon DAX1050XR

Vehicle Application:

Ford

• F-150 (With Factory Navigation): 2009 - 2012
• Flex (With Factory Navigation): 2009 - 2012
• Fusion (With Factory Navigation): 2010 - 2012
• Mustang (With Factory Navigation): 2010 - 2014

Lincoln

• MKT (With Factory Navigation): 2010 - 2012
• MKZ (With Factory Navigation): 2010 - 2012

Mercury

• Milan Hybrid (With Factory Navigation): 2010 - 2011
• Milan (With Factory Navigation): 2010 - 2011

What's in the Box:

• APX-S8-FO1-91 bracket
• S8-FO2-01 bracket
• SB-FO2-02 bracket
• S8-FO2-11 bracket
• SB-FO2-12 bracket
• Vehicle/interface harness
• mini-USB to USB-C adapter cable
• Preout harness
• Loop harness
• Antenna adapter
• 3M tape
• Pry-tool
• Ten M5x6mm screws
• Four M5x8mm screws
• 8 Nuts
• 8 Split-washers
• "GND" screw
• Quick Start Guide
