About: iDatalink Maestro APX-S8-GM1 APX 8" Radio Installation Kit for Select GM Vehicles

Specifications:

• Allows you to install a Kenwood or JVC Direct Replacement radio with a 8" floating screen in select 2019-23 Chevy Silverado and GMC Sierra trucks (also Requires the iDatalink Maestro RR2 module)
• Retains appearance of factory dash
• Retains the following factory features (if present):
  • OnStar and Bluetooth hands-free
  • Steering wheel audio controls with two function buttons and expandable radio functions
  • Backup camera with dynamic parking guidelines and park assist chimes
  • Secondary vehicle display (if factory equipped)
  • USB ports
  • Operate factory climate display/controls and vehicle settings from head unit's screen
• Adds these features:
  • Display vehicle information
  • Selectable performance gauges including "Track Pack" gauges
  • Read/reset check engine codes
• Provides 12V/15A accessory power and illumination outputs
• Provides outputs (parking brake, reverse, vehicle speed sensor [VSS]) needed to install a navigation or multimedia receiver
• Does not retain factory amplifier

Compatible Radios:

• JVC KW-Z800AW
• JVC KW-Z1000AW
• Kenwood DAX8000S
• Kenwood Excelon DAX800XR
• Kenwood Excelon DAX1050XR

Vehicle Application:

Chevrolet

• Silverado 1500 (With 8" Color Touchscreen / With Bose) (Amplifier Bypass Required): 2019 - 2021
• Silverado 1500 (With 8" Color Touchscreen / Without Amplifier): 2019 - 2021
• Silverado 2500 (With 8" Color Touchscreen / With Bose) (Amplifier Bypass Required): 2020 - 2023
• Silverado 2500 (With 8" Color Touchscreen / Without Amplifier): 2020 - 2023
• Silverado 3500 (With 8" Color Touchscreen / With Bose) (Amplifier Bypass Required): 2020 - 2023
• Silverado 3500 (With 8" Color Touchscreen / Without Amplifier): 2020 - 2023

• Sierra 1500 (With 8" Color Touchscreen / With Bose) (Amplifier Bypass Required): 2019 - 2021
• Sierra 1500 (With 8" Color Touchscreen / Without Amplifier): 2019 - 2021
• Sierra 2500 (With 8" Color Touchscreen / With Bose) (Amplifier Bypass Required): 2020 - 2023
• Sierra 2500 (With 8" Color Touchscreen / Without Amplifier): 2020 - 2023
• Sierra 3500 (With 8" Color Touchscreen / With Bose) (Amplifier Bypass Required): 2020 - 2023
• Sierra 3500 (With 8" Color Touchscreen / Without Amplifier): 2020 - 2023

What's in the Box:

• S8-GM2-01 bracket
• S8-GM2-02 bracket
• S8-GM2-11 bracket
• Vehicle/interface harness
• E-HRN-S8 harness
• C-HRN-S8 harness
• B-HRN-S8 harness
• Backup camera harness
• USB media module
• External chime
• Ribbon pack
• OBDII harness
• Antenna adapter
• USB housing
• micro-USB to USB-C cable
• micro-USB to USB-C adapter
• micro-USB to USB-A adapter
• 2 Cable-ties
• 3M tape
• Pry-tool
• Eight M5x6mm screws
• M5x8mm screw
• "GND" screw
• Quick Start Guide
