JL Audio 6W3v3-4 W3v3 Series 6.5" 150W RMS Subwoofer - SVC 4 Ohm

Name: Singh Electronics
Address: 7003 Steeles Avenue West, Toronto, ON, M9W 0A2, CA
Telephone: +1 (416) 745-1021
Price range: $

$429.95

SKU:: 6W3v3-4
UPC:: 699440921459
Condition:: New
Availability:: Usually Ships in 1-2 Days
Shipping:: Calculated at Checkout

JL Audio 6W3v3-4 W3v3 Series 6.5" 150W RMS Subwoofer - SVC 4 Ohm

$429.95

Description
Shipping & Returns

Description

About: JL Audio 6W3v3-4 W3v3 Series 6.5" 150W RMS Subwoofer - SVC 4 Ohm

If you need a small-format subwoofer that really delivers in extremely small enclosures, this is where your search ends. The 6W3v3 is a true subwoofer, through-and-through. It employs the same technologies as its larger diameter brethren to deliver a whopping 0.35 in. (8.9 mm) one-way linear excursion.

The 6W3v3-4 is best used with amplifier power in the 50W - 150W range and is optimized to operate in a tiny 0.15 cu. ft. (4.2 l) sealed enclosure, or a 0.25 cu. ft. (7.1 l) ported enclosure.

Features:

6.5" 4-ohm subwoofer
Mineral-filled polypropylene cone with nitrile-butylene rubber surround
Power range: 40-150 watts RMS
Peak power handling: 300 watts
Frequency response: 30-300 Hz
Sensitivity: 80.49 dB
Top-mount depth: 4-3/16"
Sealed box volume: 0.15 cubic feet
Grille not included

Specifications:

Continuous Power Handling (RMS): 150 W
Recommended Amplifier Power (RMS): 50 - 150 W
Nominal Impedance (Znom): 4 Ω
Nominal Diameter: 6.5 in / 165 mm
Overall Diameter: 6.85 in / 174 mm
Mounting Hole Diameter: 5.5 in / 140 mm
Bolt Hole Circle Diameter: 6.125 in / 156 mm
Motor Outer Diameter: 4.25 in / 108 mm
Mounting Depth: 4.25 in / 108 mm
Driver Displacement: 0.02 cu ft / 0.57 L
Net Weight: 6.1 lbs / 2.8 kg

Parameters:

Free Air Resonance (Fs): 41.80 Hz
Electrical “Q” (Qes): 0.533
Mechanical “Q” (Qms): 11.027
Total Speaker “Q” (Qts): 0.508
Equivalent Compliance (Vas): 0.181 cu ft / 5.13 L
One-Way Linear Excursion (Xmax)*: 0.35 in / 8.89 mm
Reference Efficiency (no): 0.07%
Efficiency (1 W / 1 m)**: 80.49 dB SPL
Effective Piston Area (Sd): 17.36 sq in / 0.0112 sq m
DC Resistance (Re): 3.476 Ω
* Xmax specifications are derived via one-way voice coil overhang method with no correction factors applied.
** Efficiency (1 W / 1 m) is not an accurate indicator of a subwoofer’s output capability and should not be used as a comparison to other subwoofers to determine which one is “louder”

Sealed Enclosure Specifications:

Wall Thickness: 0.5 in / 13 mm
Front Baffle Thickness: 0.5 in / 13 mm
Volume (net int.): 0.15 cu ft / 4.2 L
External Width (W): 8.5 in / 216 mm
External Height (H): 8.5 in / 216 mm
External Depth (D): 6.25 in / 159 mm
F3: 58.43 Hz
Fc: 62.11 Hz
Qtc: 0.7548

Ported Enclosure Specifications:

Wall Thickness: 0.5 in / 13 mm
Front Baffle Thickness: 0.5 in / 13 mm
Volume (net int.): 0.25 cu ft / 7.1 L
External Width (W): 14.50 in / 368 mm
External Height (H): 10.125 in / 257 mm
External Depth (D): 5.25 in / 133 mm
Internal Slot Port Width (SW): 4.25 in / 108 mm
Internal Slot Port Height (SH): 0.5 in / 13 mm
Internal Slot Port Length (SL): 14.75 in / 374 mm
Port Extension Length (EL): 13 in / 330 mm
Tuning Frequency (Fb): 38 Hz
F3: 34.92 Hz

Enclosure Notes:

The enclosure recommendations listed are external dimensions which assume the use of 1/2 in (13 mm) thick material. Do not use any material with a thickness of less than 1/2 in (13 mm) as this may compromise the rigidity of the enclosure
All enclosure volumes listed above are net internal volumes! Driver displacement, port displacement and brace displacement must be added to obtain the final gross internal volume. All enclosure dimensions above have already taken this into account
When using multiple subwoofers in a common enclosure you will need to recalculate the enclosure and port dimensions. For assistance please contact your authorized JL Audio dealer or JL Audio Technical Support
We recommend the use of this speaker in a bi-amplified system using high-quality satellite speakers and a high-quality amplifier. We do not recommend the use of this subwoofer with a passive crossover (coil), as this type of device will adversely affect performance
All specifications are subject to change without notice

Safety Notice:

Prolonged exposure to sound pressure levels in excess of 100dB can cause permanent hearing loss. This high-performance speaker can exceed this level. Please exercise restraint in its operation in order to preserve your ability to enjoy its fidelity
When installing a subwoofer in your vehicle, it is extremely important to secure the enclosure firmly. We recommend bolting the enclosure through the metal of the floorpan or the frame of the vehicle with large diameter washers for reinforcement. If an enclosure is not firmly attached, it can become a projectile in a collision. This is particularly important in a hatchback, station wagon, sports utility vehicle, or van

What's in the Box:

One 6.5" Subwoofer
Black plastic trim ring
Owner's Manual
