JL Audio

JL Audio C2-570X Evolution C2 Series 5" x 7"/ 6" x 8" 60W RMS 2-Way Coaxial Speakers

$369.95
SKU:
C2-570x
UPC:
699440996143
Condition:
New
Availability:
Usually Ships in 1-2 Days
Shipping:
Calculated at Checkout
Out of stock

JL Audio C2-570X Evolution C2 Series 5" x 7"/ 6" x 8" 60W RMS 2-Way Coaxial Speakers

$369.95

Out of stock

About: JL Audio C2-570X Evolution C2 Series 5" x 7"/ 6" x 8" 60W RMS 2-Way Coaxial Speakers

C2 systems deliver sparkling high-frequency detail, smooth mid-range and powerful mid-bass, thanks to real silk dome tweeters and precision-engineered woofer designs.

Many people mistakenly believe that an oval speaker cannot perform as well as a round one, leading to many instances of 5.25-inch speakers being installed into 5 x 7-inch openings. JL Audio has put in the engineering time and effort to create fantastic-sounding speakers that drop into oval openings and deliver equivalent performance to our 6.5-inch (165 mm) round speaker systems... guaranteed. So, don't make the mistake of losing cone area and efficiency by stepping down to a smaller round speaker... these ovals are as impressive as our round format systems.

The C2-570x system features 5 x 7 / 6 x 8-inch (125 x 180 mm) woofers with mineral-filled polypropylene cones, long excursion capabilities and stamped steel frames. The woofer design benefits from JL Audio's vast woofer design experience and advanced modelling systems.

Tweeters are coaxially mounted and built with 0.75-inch silk dome diaphragms that deliver smooth, extended response, on and off axis. The small size of the C2 tweeter minimizes tweeter protrusion, allowing C2 coaxials to fit behind most factory speaker grilles. Grilles are not available for this speaker system. Sold as a pair.

Specifications:

  • Continuous Power Handling (RMS): 60 W
  • Recommended Amplifier Power (RMS): 15 - 100 W / Ch.
  • System Efficiency: 90.5 dB @ 1 W / 1 m
  • System Nominal Impedance: 4 Ω
  • System Frequency Response: 53 Hz - 22 KHz ± 3 dB

Coaxial Physical Specifications:

  • Frame Outer Diameter*: 5.47 x 7.68 in / 139 x 195 mm
  • Grille Tray Outer Diameter: N/A
  • Motor Outer Diameter: 2.76 in / 70 mm
  • Frontal Coaxial Tweeter Protrusion**: 0.47 in / 12 mm
  • Frontal Grille Protrusion: N/A
  • Mounting Hole Diameter: N/A
  • Mounting Depth: 2.43 in / 62 mm
  • *Does not take into account mounting tabs
  • **Frontal coaxial tweeter protrusion measured from mounting surface

What's in the Box:

  • Two 5x7" 2-way speakers
  • 2 Bottom-mount spacer rings
  • 8 Self-tapping screws (#8 x 1-3/16")
  • 8 Speed clips
  • Two Crimpable female quick slides (0.205"/5.2mm)
  • 2 Crimpable female quick slides (0.11"/2.8mm)
  • Owner's Manual
