About: JL Audio C2-600X Evolution C2 Series 6" 60W RMS 2-Way Car Speakers
Coaxial Speaker System: 6-inch (150 mm) Woofer, 0.75-inch (19 mm) Silk Dome Tweeter
C2 systems deliver sparkling high-frequency detail, smooth mid-range and powerful mid-bass, thanks to real silk dome tweeters and precision-engineered woofer designs.
The C2-600x system features 6-inch (150 mm) woofers with mineral-filled polypropylene cones, long excursion capabilities and stamped steel frames. The woofer design benefits from JL Audio's vast woofer design experience and advanced modelling systems.
The 6-inch (150 mm) format is a direct fit in many vehicles. Multiple mounting patterns are provided on the woofer frame for easy installation into most vehicles that accept a 6.5-inch (165 mm) speaker.
Tweeters are coaxially mounted and built with 0.75-inch silk dome diaphragms that deliver smooth, extended response, on and off axis. The small size of the C2 tweeter minimizes tweeter protrusion, allowing C2 coaxials to fit behind most factory speaker grilles.
Woofer grilles are included, each consisting of a black grille tray with satin silver accents and a black steel mesh grille with an electroformed JL Audio logo.
Sonic character: Clean and Dynamic
Sold as a pair.
General Specifications:
- Continuous Power Handling (RMS): 60 W
- Recommended Amplifier Power (RMS): 15 - 100 W / Ch.
- System Efficiency: 90.5 dB @ 1 W / 1 m
- System Nominal Impedance: 4 Ω
- System Frequency Response: 59 Hz - 22 KHz ± 3 dB
Coaxial Physical Specifications:
- Frame Outer Diameter*: 6.21 in / 158 mm
- Grille Tray Outer Diameter: 6.51 in / 163 mm
- Motor Outer Diameter: 3.15 in / 80 mm
- Frontal Coaxial Tweeter Protrusion**: N/A
- Frontal Grille Protrusion***: 0.91 in / 23 mm
- Mounting Hole Diameter: 5.00 in / 127 mm
- Mounting Depth: 2.38 in / 64 mm
- *Does not take into account mounting tabs
- **Frontal coaxial tweeter protrusion measured from mounting surface
- ***Frontal grille protrusion measured from mounting surface
Features:
- 2-way 6" speakers (pair)
- Injection-molded mica-filled polypropylene woofer with butyl rubber surround
- 3/4" silk dome tweeter
- Built-in crossover network
- 4-ohm impedance
- Handles up to 60 watts RMS (225 watts peak power)
- Frequency response: 59-22,000 Hz
- Sensitivity: 90.5 dB
- Depth: 2-3/8"
- Grilles included
What's in the Box:
- Two 2-way speakers
- 2 Grilles
- 8 Self-tapping screws (#8 x 1-3/16")
- 8 Speed clips
- Two Crimpable female quick slides (0.205"/5.2mm)
- 2 Crimpable female quick slides (0.11"/2.8mm)
- 2 JL Audio logo badges
- Owner's Manual
- Paper template
