About: JL Audio HD900/5 HD Series 5-Channel Car Amplifier — 100W RMS x 4 + 500W RMS x 1

Thanks to its ability to act as a "one-box solution", the HD900/5 is ideal for installations where space is at a premium and sound quality is the paramount goal. While extremely compact, this amazing amplifier will comfortably drive a complete high-performance car audio system: that is, four satellite speaker systems and a subwoofer system... with a very serious 900 watts of power!

Using our Single Cycle Control switching design and R.I.P.S. technology, the HD900/5 delivers 100 W x 4 to its four main channels, plus a very meaty 500 W to its subwoofer channel. Thanks to R.I.P.S., high power can be delivered over a wide range of load impedances, while the tight power supply regulation keeps distortion down, maximizing sound quality. From a pure sound quality perspective, we invite you to compare the real-world, in-car performance of this amplifier to any other amplifier on the market, of any type, at any price.

This amplifier features a brushed aluminum finish with black powder-coated cast alloy heat sinks and bottom panel. A black powder-coated, gasketed cover is also provided to protect the controls.

Features:

  • 5-channel amplifier
  • 100 watts RMS x 4 at 4 ohms + 500 watts RMS x 1 (at 1.5-4 ohms)
  • 75 watts RMS x 4 (at 1.5-3 ohms) + 500 watts RMS x 1 (at 1.5-4 ohms)
  • 150 watts RMS x 2 bridged (at 3-6 ohms) + 500 watts RMS x 1 at (1.5-4 ohms)
  • Variable high-pass filter on front and rear channels (50-500 Hz, 12 or 24dB/octave)
  • Variable low-pass filter on subwoofer channel (50-500 Hz, 12 or 24dB/octave)
  • Subsonic filter on sub channel (24 dB/oct at 30 Hz)
  • Removable power and speaker plugs
  • Optional wired remote for level control
  • Optional HD stacking kit for stacking multiple HD amps together
  • Class D amplifier design
  • MOSFET power and output stages
  • Differential-balanced inputs eliminate noise from your vehicle's electrical system
  • Speaker- and preamp-level inputs (speaker-level input requires an optional adapter)
  • Preamp outputs
  • Dimensions (W x H x D): 10.74" x 1.93" x 7.85" (273 x 49 x 199 mm)
  • Weight: 6.85 lb (3.11 kg)

Specifications:

  • Rated Continuous (RMS) Power @ 14.4 V:
    • Main Channels @ 4 Ω: 100 W RMS x 4
    • Main Channels @ 3 Ω: 75 W RMS x 4
    • Main Channels @ 2 Ω: 75 W RMS x 4
    • Main Channels @ 1.5 Ω: 75 W RMS x 4
    • Main Channels - Bridged @ 8 Ω: 200 W RMS x 2
    • Main Channels - Bridged @ 4 Ω: 150 W RMS x 2
    • Subwoofer Channel @ 4 Ω: 500 W RMS x 1
    • Subwoofer Channel @ 3 Ω: 500 W RMS x 1
    • Subwoofer Channel @ 2 Ω: 500 W RMS x 1
    • Subwoofer Channel @ 1.5 Ω: 500 W RMS x 1
  • Rated Continuous (RMS) Power @ 12.5 V:
    • Main Channels @ 4 Ω: 100 W RMS x 4
    • Main Channels @ 3 Ω: 75 W RMS x 4
    • Main Channels @ 2 Ω: 75 W RMS x 4
    • Main Channels @ 1.5 Ω: 75 W RMS x 4
    • Main Channels - Bridged @ 8 Ω: 200 W RMS x 2
    • Main Channels - Bridged @ 4 Ω: 150 W RMS x 2
    • Subwoofer Channel @ 4 Ω: 500 W RMS x 1
    • Subwoofer Channel @ 3 Ω: 500 W RMS x 1
    • Subwoofer Channel @ 2 Ω: 500 W RMS x 1
    • Subwoofer Channel @ 1.5 Ω: 500 W RMS x 1
  • Frequency Response (Main Channels): 12 Hz - 28 kHz (+0, -1dB)
  • Frequency Response (Subwoofer Channel): 12 Hz - 10 kHz (+0, -1dB)
  • S/N Ratio, referred to highest rated power (Main Channels): >108.5 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth)
  • S/N Ratio, referred to 1 W (Main Channels): >88.2 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
  • Damping Factor @ 4 Ω: >400 / 50 Hz
  • Damping Factor @ 2 Ω: >200 / 50 Hz
  • THD+N @ Rated Power (Main Channels): <0.03% @ 4 Ω
  • THD+N @ Rated Power (Subwoofer Channel): <0.05% @ 4 Ω
  • Input Voltage Range @ RCA Inputs: Switchable from 200 mV - 2 V RMS (Low) to 800 mV - 8 V RMS (High)
  • Min.Copper Power / Ground Wire Gauge: Accepts up to 4 AWG wire
  • Fuse Rating: 60 A (AFS, AGU or MaxiFuse™)

Signal Processing:

  • Filter Mode(s): Channels 1 & 2 (front): High-Pass only
  • Filter Slope(s): Channels 1 & 2 (front): 12/24 dB/octave
  • Filter Frequency Range: Channels 1 & 2 (front): 50 Hz - 500 Hz
  • Filter Mode(s): Channels 3 & 4 (rear): High-Pass only
  • Filter Slope(s): Channels 3 & 4 (rear): 12/24 dB/octave
  • Filter Frequency Range: Channels 3 & 4: 50 Hz - 500 Hz
  • Filter Mode(s): Subwoofer Channel: Low-Pass only
  • Filter Slope(s): Subwoofer Channel: 12/24 dB/octave
  • Filter Frequency Range: Subwoofer Channel: 50 Hz - 500 Hz
  • Detented, Calibrated Filter Freq. Potentiometers: Yes
  • Filter Defeat Function: Yes
  • Infrasonic Filter: Subwoofer Channel: 30 Hz, Defeatable
  • Remote Level Control: Optional (HD-RLC)
  • Remote Level Modes: Sub Ch. only
  • Channel Input Mode Switch: Yes (2/4/6 ch.)
  • Pass-Through Preamp Output: None
  • Source Channel Selection for PreOuts: N/A

What's in the Box:

  • 5-Channel class-D full-range amplifier
  • Power/Ground/Turn-On plug
  • 3 Speaker connection plugs
  • 3mm Allen-wrench
  • 5mm Allen-wrench
  • Mounting bolts
  • Owner's Manual
