Descriptions

About: JL Audio RD800/6 6-Channel Car Amplifier — 75W RMS x 4 + 150W RMS x 2

Features:

• 6-channel car amplifier
• 75 watts RMS x 4 + 150 watts RMS x 2 at 4 ohms
• 100 watts RMS x 4 + 200 watts RMS x 2 at 2 ohms
• 200 watts RMS x 2 bridged at 4 ohms + 400 watts RMS x 1 bridged at 4 ohms (4-ohm stable in bridged mode)
• Class D amplifier design with NextD™ switching amp technology
• differential-balanced inputs help eliminate noise
• variable high-pass filters (50-5000 Hz, 12 dB/octave) on channels 1 and 2, variable high-pass filters (50-500 Hz, 12 dB/octave) on channels 3 and 4, and 5 and 6
• bandpass filters on channels 3 and 4, and 5 and 6
• LED clip lights help set gain
• blue LED accent lighting
• preamp and speaker-level inputs (speaker wire to RCA adapter required for speaker-level input)
• 4-gauge power and ground leads and 80-amp fuse recommended — wiring and hardware not included with amplifier
• no onboard fuses — when installing multiple amps in a system, an additional 80-amp in-line fuse between the distribution block and the amplifier is recommended

Specifications:

• RMS Power Output (Watts x Channels): 75 x 4
• Power at 2 Ohms (Watts x Channels): 100 x 4
• Bridged Power (Watts x Channels): 200 x 2
• Minimum Impedance Bridged: 4
• Best Frequency Response: 12Hz-22k Hz
• THD at Rated RMS Power: 1%
• Signal to Noise Ratio: 84 dB
• Input Voltage: 14.4v
• Amplifier: Class D
• Built-in DSP: No
• Remote Control: No
• Low-Pass Crossover Frequency: 50-500 Hz
• Low-Pass Slope (dB/octave): 12 dB/oct
• High-Pass Crossover Frequency: 50-5000 Hz
• High-Pass Slope (dB/octave): 12 dB/oct
• Bass Boost: No
• Bass Boost Frequency: N/A
• Fan Cooled: No
• Fuse Rating: 80
• Speaker Level Inputs: Yes
• Preamp Outputs: No
• Dimensions: 14.62"W x 2.17"H x 6.97"D
