About: JL Audio VX1000/5i 5-Channel Car Amplifier with Digital Signal Processing — 75W RMS x 4 + 600W RMS x 1
5-Channel Class D System Amplifier with Integrated DSP, 100 W x 4 @ 2 Ω + 600 W x 1 @ 2 Ω - 14.4V
Designed to simplify great audio, every VXi amplifier combines our advanced NexD2™ switching amplifier technology with an integrated, full-featured digital signal processor.
Employing our second generation NexD2™ amplifier technology, the VX1000/5i efficiently powers a complete audio system. It can drive four main speakers with 75 W x 4 @ 4 ohms while also powering a subwoofer with up to 600W @ 2 ohms. Bridging the main channels converts it into a very powerful, 3-channel system amplifier with up to 200W x 2 @ 4 ohms on the main channels and 600W @ 2 ohms on the subwoofer channel.
The NexD2™ full-range technology in the main channels of this amplifier is DSP-controlled and features a reduced loop area design utilizing DirectFET™ outputs for outstanding fidelity, very low noise and exceptional efficiency. The subwoofer channel features an optimized low-frequency variant of the NexD2™ technology. The amplifier chassis is ultra-compact, with all connections on one side, to greatly simplify installation into tight spaces.
Instead of traditional control knobs and switches, all amplifier adjustments and DSP functionality are configured via a compatible external device (PC, Tablet or Smartphone), with the appropriate JL Audio TüN® Software application installed.
Amplifier includes: Power Connector (for 2 AWG wire), Analog Input/Pre-Out Harness, Speaker Output Harness, Subwoofer Output Connector, 6 ft A/B USB Cable
Features:
Unprecedented, Onboard DSP Tuning Power!
- Powerful DSP permits optimizing each channel’s timing, frequency response and output levels, for exceptional sound quality.
- TüN™ Software delivers fast and easy setup, at your fingertips. Make all adjustments with a clear interface. Free TüN™ software is available for computers and most handheld devices.
2nd-Gen NexD2™ Switching Amplifier Technology
- Advanced, high-speed switching technology delivers reference-grade power and efficiency.
- DSP-synchronized power supply and output channels produce world-class sound quality with very low noise and distortion.
Ultra-Versatile Analog and Digital Inputs/Outputs
- Differential-Balanced Analog Inputs accept speaker level signals up to 16V RMS, including those from factory systems. Delivers outstanding noise rejection to prevent alternator whine and other noises.
- Optical Digital (Toslink) Inputs permit direct connection of S/PDIF digital sources, bypassing A/D converter. Accepts up to 24 bit/192 kHz input.
- Analog and Digital Pre-Outs (pass-through or fully configurable): RCA Pre-Outs (4V RMS Max) and Optical (Toslink) Output at 24 bit/96 kHz
- Automatic turn-on options via signal-sensing or DC-offset sensing
JLid™ System Command and Control with Networking Capabilities
- Proprietary JL Audio protocol provides control interface and all communication for VXi amplifiers and optional JLid™ accessories, including:
DRC-100 / DRC-205 (Digital Remote Controllers): Offers convenient DSP preset selection and level adjustments from the driver’s seat.
VXi-BTC Bluetooth® Communicator: Adds wireless connectivity for amplifier configuration from a compatible iOS® or Android® device.
VXi-HUB Optical Network Hub: Provides network connectivity for up to six VXi amplifiers, allowing full-system DRC control and preset selection. Up to two VXi-HUBs can be daisy-chained to control up to ten VXi amplifiers.
Specifications:
Rated Continuous (RMS) Power @ 14.4 V
- Main Channels @ 4 Ω 75 W RMS x 4
- Main Channels @ 2 Ω 100 W RMS x 4
- Main Channels - Bridged @ 4Ω 200 W RMS x 2
- Subwoofer Channel @ 4 Ω 400 W RMS x 1
- Subwoofer Channel @ 3 Ω 500 W RMS x 1
- Subwoofer Channel @ 2 Ω 600 W RMS x 1
- Subwoofer Channel @ 1.5 Ω N/A
Rated Continuous (RMS) Power @ 12.5 V
- Main Channels @ 4 Ω 60 W RMS x 4
- Main Channels @ 2 Ω 90 W RMS x 4
- Main Channels - Bridged @ 4Ω 180 W RMS x 2
- Subwoofer Channel @ 4 Ω 360 W RMS x 1
- Subwoofer Channel @ 3 Ω 480 W RMS x 1
- Subwoofer Channel @ 2 Ω 600 W RMS x 1
- Subwoofer Channel @ 1.5 Ω N/A
General Specifications:
- Frequency Response (Main Channels): 12 Hz - 21 kHz (+0, -1dB)
- Frequency Response (Subwoofer Channel): 12 Hz - 1 kHz (+0, -1dB)
- S/N Ratio, referred to highest rated power (Analog Inputs - Main Channels): 99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- S/N Ratio, referred to highest rated power (Analog Inputs - Main Channels): 99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- S/N Ratio, referred to highest rated power (Analog Inputs - Subwoofer Channel): 99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- S/N Ratio, referred to 1 W (Analog Inputs - Main Channels): 80 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- S/N Ratio, referred to 1 W (Analog Inputs - Subwoofer Channel): 72 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- S/N Ratio, referred to highest rated power (Digital Inputs - Main Channels): 100 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- S/N Ratio, referred to highest rated power (Digital Inputs - Subwoofer Channel): 99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- S/N Ratio, referred to 1 W (Digital Inputs - Main Channels): 81 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- S/N Ratio, referred to 1 W (Digital Inputs - Subwoofer Channel): 73 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
- Damping Factor @ 2 Ω: >50 / 50 Hz
- Damping Factor @ 4 Ω: >150 / 50 Hz
- THD+N @ Rated Power (Main Channels): <1% @ 2 Ω per Ch.
- THD+N @ Rated Power (Subwoofer Channels): <1% @ 2 Ω per Ch.
- Input Voltage Range @ RCA Inputs: 200 mV - 16 V RMS
- Min.Copper Power / Ground Wire Gauge: 4 AWG wire
- Fuse Rating: 80 A (AFS, AGU or MaxiFuse™)
Other Features:
- 5-channel car amplifier
- 75 watts RMS x 4 + 400 watts RMS x 1 (at 4 ohms)
- 100 watts RMS x 4 + 600 watts RMS x 1 (at 2 ohms)
- 200 watts RMS x 2 bridged at 4 ohms + 600 watts RMS x 1 at 2 ohms
- Class D amplifier design with NexD2™ switching amp technology
Digital Signal Processing:
- 24-bit 96 kHz digital processing
- DSP adjustments and settings made with JL Audio's TüN app (PC and Mac) via USB, via Bluetooth (tablets and phones) with BTC Bluetooth option
- Input routing and mixing
- Adjustable gain controls with clip indication
- Fully adjustable high-pass, low-pass, and bandpass filters
- Selectable filter slopes (6, 12, 18, 24, 30, 36, 42, 48 dB/octave)
- 10-band EQ
- Phase and polarity control
- Time alignment in 0.01 ms (1/8") increments
Connection Features:
- Differential-balanced inputs eliminate noise coming from your vehicle's electrical system
- Preamp and speaker-level inputs (speaker wire to RCA adapter required for speaker-level input)
- High-level inputs — up to 16 volts RMS (about 60 watts)
- DC offset or signal sensing auto turn-on eliminates need for remote lead
- 2-channel digital input and output (S/PDIF: up to 24-bit 192 kHz in, 24-bit 96 kHz out)
- 2-channel analog preamp output (4V RMS)
- JLid™ connections for optional Network Hub, Bluetooth Communicator, and Digital Remote Control
- USB connection for device running TüN app (6-foot cable included)
- Wiring, fuse, and hardware not included with amplifier
- 4-gauge power and ground leads and an 80-amp fuse recommended
- 11-5/16"W x 2-1/8"H x 6-11/16"D
What's in the Box:
- 5-Channel amplifier
- Power connector
- 14" Analog Input harness (25-pin D-Sub/8 RCA)
- 18" ABCD Speaker output harness
- Subwoofer output connector
- 18" Speaker wire loom
- "Sub" wire label
- 6' USB cable (Type A USB on one end and Type B USB on other end)
- 4 Corner caps
- Corner cap tool
- 2 Silver thumbscrews
- 2 Black hex cap machine screws
- 2.5mm Hex wrench
- 3mm Hex wrench
- JL Audio logo badge
- Connection Guide
- Registration card
