JL Audio XDM600/1 600W RMS Car/Marine Monoblock Amplifier

video

video
video gallery

have questions?

+1 (416) 745-1021

Ask an Expert

Guaranteed Fitment

Always the correct part
In-House Experts

We know our products
Installation Assistance

We're happy to help
Canada Wide Delivery

Free shipping on orders over $200*

JL Audio

JL Audio XDM600/1 600W RMS Car/Marine Monoblock Amplifier

Name: Singh Electronics
Address: 7003 Steeles Avenue West, Toronto, ON, M9W 0A2, CA
Telephone: +1 (416) 745-1021
Price range: $

$899.95

$719.95

SKU:: XDM600/1
UPC:: 699440986830
Condition:: New
Availability:: Usually Ships in 1-2 Days
Shipping:: Calculated at Checkout

JL Audio XDM600/1 600W RMS Car/Marine Monoblock Amplifier

$899.95

$719.95

Description
Shipping & Returns

Description

About: JL Audio XDM600/1 600W RMS Car/Marine Monoblock Amplifier

This potent monoblock amplifier employs our high-speed NexD™ switching design to achieve unprecedented efficiency and amazing power output from a very compact chassis. Don't let its small size fool you, though... the XDM/600/1 generates serious subwoofer power, delivering a full 600 W of continuous power into a 2 ohm load (14.4V, 1% THD).

Designed for car or boat installations, the XDM600/1 is built with marine-grade materials and features an exclusive, dual-mode input filter for noise-free performance in boats or cars. Automatic turn-on capability (via signal sensing or DC-offset sensing) is also onboard for easy factory system upgrades.

Targeted specifically for subwoofer applications, the XDM600/1 includes a variable slope low-pass filter with continuously variable cutoff frequency selection from 50-500 Hz. With the addition of an optional HD-RLC or MHD-RLC (water-resistant) remote level controller (each sold separately), the amplifier's level can be adjusted directly from the driver's seat or captain’s chair. Finished in a sleek, black powder-coat, all controls are protected beneath a gasketed, removable top cover for easy access.

Features:

Mono car/marine subwoofer amplifier
- 400 watts RMS x 1 at 4 ohms
- 600 watts RMS x 1 at 2 ohms
Variable low-pass filter (50-500 Hz, 12 or 24 dB/octave)
Switchable subsonic filter (30 Hz, 24 dB/oct)
Class D amplifier design with NextD™ switching amp technology
Differential-balanced inputs help eliminate noise
Weather-resistant chassis: black powder-coat finish, gasketed control cover, stainless steel hardware
Optional wired remote level control available
Preamp and speaker-level inputs
- Switchable input filter (car/boat) eliminates interference from onboard high-current devices
- Speaker-level inputs handle up to 4Vrms (about 4 watts)
- Speaker-level inputs require Wire-to-RCA adapters
- Speaker-level inputs feature auto turn-on via DC offset or signal sensing
Preamp outputs
Dimensions (W x H x D): 8.52" x 2.05" x 7.09" (216 x 52 x 180 mm)
Weight: 6.3 lb (2.86 kg)

Specifications:

Rated Continuous (RMS) Power @ 14.4 V:

@ 4 Ω400 W RMS x 1
@ 3 Ω500 W RMS x 1
@ 2 Ω600 W RMS x 1
@ 1.5 Ω N/A

Rated Continuous (RMS) Power @ 12.5 V:

@ 4 Ω300 W RMS x 1
@ 3 Ω400 W RMS x 1
@ 2 Ω500 W RMS x 1
@ 1.5 ΩN/A

Frequency Response: 7 Hz - 500 Hz (+0, -1dB)
S/N Ratio, referred to highest rated power: >87 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W: >67 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
Damping Factor @ 4 Ω: >1000 / 50 Hz
Damping Factor @ 2 Ω: >500 / 50 Hz
THD+N @ Rated Power: <1% @ 2 Ω per Ch.
Input Voltage Range @ RCA Inputs: 200 mV - 4 V RMS
Min.Copper Power / Ground Wire Gauge: 4 AWG wire
Fuse Rating: 50 A (AFS, AGU or MaxiFuse™)

Signal Processing:

Filter Mode(s): Low-Pass only
Filter Slope(s): 12/24 dB/octave
Filter Frequency Range: 50 Hz - 500 Hz
Detented, Calibrated Filter Freq. Potentiometer: Yes
Filter Defeat Function: Yes
Infrasonic Filter: 30 Hz, defeatable
Bass Boost EQ: No
Output Polarity Switch: No
Remote Subwoofer Level Control: Optional HD-RLC or b (water-resistant)
Remote Bass EQ Boost Control: No
Pass-Through Preamp Output: Buffered

What's in the Box:

Mono car/marine amplifier
Self-adhesive JL Audio badge
2.5mm Allen wrench
Owner's Manual
Warranty information
