Special capacitors and inductors have been carefully selected for the digital amplifier’s LC filter, which is essential for achieving high resolution audio. These high-performance parts reduce noise and distortion and ensure excellent sound quality.

By using a down-firing subwoofer and superior technologies, the audio system generates high-quality sound and powerful bass, while still being compact.

The feedback value of the current XR Amplifier has been optimized to improve the S/N ratio. As a result, the noise level has been reduced by up to 40%.

The noise reduction system employs a special layout that separates the analog circuit, digital amplifier circuit and power supply circuit. This keeps interference between the circuits to a minimum, decreasing noise and thereby achieving high performance and sound quality.

Product Highlights:

• Mono subwoofer amplifier
• 400 watts RMS x 1 at 4 ohms (600 watts RMS x 1 at 2 ohms)
• CTA-2006 compliant
• Class-D amp design — frequency response: 20-200 Hz
• variable low-pass filter (50-200 Hz at 24 dB/octave)
• adjustable bass boost (0-18 dB at 40 Hz)
• wired remote volume control included
• preamp inputs only
• fuse rating: 30A x 3
• wiring and hardware not included with amplifier
• Dimensions (W x H x D): 8-11/16" x 1-3/8" x 7"

What's in the Box:

• Mono subwoofer amplifier
• Three 30A ATM mini-blade fuses (installed)
• Remote Commander
• Flat washer
• Hex nut
• 20' Remote cable (RJ-14 modular plugs on each end)
• 4mm Allen wrench
• 2.5mm Allen wrench
• Four 5/8" self-tapping screws
• Instruction Manual (Eng / Fren / Span)
• Warranty card
