About: Klipsch PRO-16RC 6.5" In-Ceiling Speaker with 1" Aluminum Dome Tweeter

Featuring a 6.5” Injection Molded Graphite (IMG) Woofer and 1” Pivot Aluminum Dome ABS Tractrix® Horn-Loaded Tweeter, the PRO-16RC brings incredible acoustics with the signature Klipsch sound. Featuring the SecureFit™ Installation System, the Klipsch Professional Series Reference speakers are the ideal choice for custom home installation audio.

True Reference Acoustics

Using the same acoustic components and horn design as the highly acclaimed Reference box speaker line, the Professional Reference Architectural series perfectly combines the aesthetics of an architectural speaker with the pure performance and dynamic voicing of the Klipsch Reference series. With a 6.5” IMG woofer and a 1” Aluminum Dome tweeter mated to a round Tractrix® horn, the Pro-16RC brings dynamic, powerful, detailed Klipsch Reference sound to your distributed audio or home theater system.

SecureFit™ Installation System

The exclusive modular installation system allows for the dog legs to be engaged by hand to a preset clamping force, eliminating the possibility of overtorquing, which can lead to breaking the dog leg or cracking the drywall. The speaker module is then screwed to the bezel (using machine screws instead of traditional drywall screws) for a more robust, acoustically stable installation than the competition.

Controlled Dispersion Technology™

CDT technology allows for the tweeter and the woofer to be aimed up to 15° in any direction, helping to ensure on-axis frequency response at almost any listening position.

All New, Bezel-Free Magnetic Grille

A completely redesigned powercoated magnetic steel grille eliminates the bezel for seamless, pristine integration into the living space.

Round and Square Grilles Included

Architectural speakers not only need to sound great, but blend in seamlessly with even the most luxurious interior designs. The Professional Series Reference Premiere in-ceiling speakers include both round and square grilles in the box, so they look great in any space right out of the box.

PVC Paint Shield Included

Also included is a magnetic PVC paint shield that can be used to cover the speaker module to protect it from paint or construction dust during renovations or remodels.

Features:

• 6.5” Injection Molded Graphite (IMG) Woofer
• 1” Pivot Aluminum Dome ABS Tractrix® Horn-Loaded Tweeter
• Exclusive, modular SecureFit™ Installation System
• Bezel-Free square and round paintable magnetic grilles
• Controlled Dispersion™ Technology

Specifications:

• Frequency Range: 63Hz - 23kHz +/- 3dB
• High Frequency Driver: 1" (2.54cm) Aluminum Dome Tweeter mated to a round Tractrix® Horn
• Low Frequency Driver: 6.5" (16.51cm) IMG Woofer
• Sensitivity: 94 dB @ 2.83V / 1m
• Coverage Angle: 100°
• Power Handling: 50W RMS / 200W Peak
• Impedance: 8 Ohm Compatible
• Enclosure Material/Type: ABS/Infinite Baffle
• Finish: Black Baffle/Frame, White Paintable Grille
• Product Dimensions: 9.33” W x 9.33” H x 6.38” D (23.7cm H x 23.7cm W x 16.2cm D)
• Mounting Depth: 6.14” (15.6cm)
• Cutout Dimensions: 8.15” (20.7cm)
• Product Weight: 7.47 lbs (3.39kg)
• Included in Box: Round Grille, Square Grille, Paint Shield
• Install Kit: IK-650-C II (Sold Separately)
• Built From: 2017
