About: Pioneer GM-ME300X1C 300W RMS Compact Monoblock Marine Amplifier
Pioneer GM-ME300X1C is a Class-D Monaural marine amplifier, which is IP67 rated and is SAE J1171 Certified. This amplifier features top adjustment access that benefits when installing into narrow compartments. Its 21-step frequency selection has a new feature that firmly clicks into position. A microcomputer provides controlled current and voltage protection to ensure stable output operation.
Digital controlled Class-D Amplifier Circuit
This amplifier features a 32-bit floating-point DSP to modulate the input signal which improves audio performance for the highest levels of accuracy, stability, channel symmetry, and high signal-to-noise performance.
Top Chassis Adjustment Access
Extremely flexible in a variety of environmental conditional, the sealed top chassis cover is removable to easily access adjustment setting options.
Dust & Waterproof Design
This marine amplifier is IP67 rated for dust and water resistance when installed with the included control panel cover. Total protection against dust ingress and protection against short periods of immersion in water (maximum 30 minutes at 1 meter/3.28ft. depth).
Class D Audio Amplifier with Micro Controller Unit design (MCU)
Pioneer is a Class D Marine Amplifier features an MCU design, utilizing a microprocessor to enable and control the amplifier’s audio, power and protection circuits.
Protection Control System (PCS)
Pioneer’s PCS continuously monitors the input voltage, current consumption, and operating temperature to automatically adjust the amplifier’s output to ensure operational stability during long listening sessions or when installed in high-temperature environments.
SAE J1171 Certified
This amplifier is SAE J1171 certified for external ignition protection of Marine Electrical Devices. This recommended practice covers all electrical devices suitable for use in marine engine compartments and fuel tank spaces.
PCB Layout and Design
The PCB for this Pioneer amplifier is made of a glass epoxy substrate which is strong, water-resistant, and provides good insulation between layers to minimize interference while promoting accurate signal with increased electrical connectivity.
Flexible Adjustment Settings - Mono
Adjustments to the built-in low pass filter featuring a precise 21-step frequency range, 0dB/ 6dB/ 12dB adjustable bass boost, gain, and input setting deliver precise adjustability to deliver high-quality sound.
Specifications:
- mono marine subwoofer amplifier
- 300 watts RMS x 1 at 2 and 4 ohms
- CTA-2006 compliant
- frequency response: 10-240 Hz
- variable low-pass filter (50-500 Hz, 12 dB/octave)
- selectable bass boost (0, 6, 12 dB)
Other Features:
- conformal coated circuit boards
- IP67 rated for dust and water resistance
- rubber covers protect top panel controls, RCA terminals, and fuses
- preamp and speaker-level inputs (RCA adapters included)
- wiring and hardware not included with amplifier
- 8-gauge power and ground leads recommended
- fuse rating: 30A x 1
- dimensions (W x H x D): 11-13/16" x 1-5/8" x 4-1/8"
What's in the Box:
- 1-Channel Marine Subwoofer Amplifier
- One 30-amp ATO fuse in-line (installed)
- Power Harness (1)
- Speaker Line Input RCA Cable (1)
- Installation Screws X 4
- Supplied Tool (2)
- Owner's manual (English/ French/Spanish)
- 1 Year Warranty sheet
