About: PRV Audio 10MR1000X 10" 500W RMS Midrange Loudspeaker - 8 Ohm (Each)

X-treme mid range performance is what PRV Audio’s 10MR1000X is all about. The PRV Audio 10MR1000X is the evolution of our line, after intense 2 years of development we have created the mid range loudspeaker that offers outstanding durability. This specially designed loudspeaker is assembled with top of the line components for long lasting play, even during intense use.

A coated woven surround offers smooth, precise geometry during hard play. The light weight cone provides excellent linear response up to 3 kHz, making the 10MR1000X a great solution for high quality two or three-way systems.

Extreme car audio enthusiasts will find PRV Audio’s 10MR1000X to be the perfect 10? mid range door speaker, capable of handling up to 500 watts RMS power (with a suggested 140 Hz, 18 dB/octave high pass filter in place)! The large magnet assembly is attached to a sturdy, reinforced cast-aluminum frame.

High power handling at sensitivity rating of 100 dB 1W/1M which makes it capable of generating a lot of output!

Product Highlights:

• 3″ Inside/Out aluminum voice coil wound on fiberglass former for hi-temp performance, 8 ohms
• 1,000 watts continuous program power rating makes high acoustical output
• Excellent performance in compact enclosures
• 100 dB sensitivity, which makes it capable of generating a lot of output!
• Detailed vocal reproduction, high fidelity response

Specifications:

• Nominal Diameter: 10" (254 mm)
• Nominal Impedance: 8 Ohms
• Rated AES Power Handling (RMS): 500 Watts
• Program Power: 1000 Watts
• Sensitivity 2.83v at 1m: 100 dB
• Recommended Hi Pass Crossover: 150 Hz**12dB Per Octave Crossover
• Frequency Response at -10dB: 75 - 6,500 Hz
• Voice Coil Diameter: 3" (76 mm)
• Voice Coil Wire: Copper
• Voice Coil Winding Depth: 9.0 mm
• Former Material: Glass Fiber
• Magnetic Gap Depth: 8.0 mm
• Frame Material: Die Cast Aluminum
• Sold individually

Thiele-Small Parameters

• Equivalent Volume (Vas): 28.68 l
• Excursion (Xmax): 2.50 mm
• Free Air Resonance (Fs): 72.02 Hz
• Mechanical Factor (Qms): 11.22
• Electrical Factor (Qes): 0.23
• Total Factor (Qts): 0.22
• Cone Area (Sd): 3.91 cm²
• Mechanical Mass (Mms): 36.26 g
• Bl Factor (Bl): 19.42 Tm
• Dc Resistance (Re): 5.2 Ohms
• Inductance (Le): 0.43 mH at 1 kHz
• Mechanical Mass Without Air (Mmd): 31.89 g
• Mechanical Compliance (Cms): 0.134 mm/n

Mounting and Shipping Information:

• Overall Diameter: 10.23" (260 mm)
• Front Mount Baffle Cutout: 9.01" (229 mm)
• Mounting Depth: 4.27" (108.5 mm)
• Overall Depth: 4.84" (123 mm)
• Net Weight: 15.43 Lbs (7.0 kg)
• Shipping Weight: 16.53 Lbs (7.5 kg)
