The PRV 12MB1500FT has an excellent linear response, well controlled down to 75 Hz, which makes it a great option for 2-way cabinet systems that require strong BL magnet force and midbass punch. A great new addition to the Forte Series, where more power handling and less distortion on mid low mid bass frequencies is the key.

Supporting the cone is a heavy duty spider M roll treated cloth surround, designed for high excursion applications to handle short bursts of excessive power without damage. A double silicon spider system ensures excellent control during large excursions of 1.50″ peak-to-peak excursion before damage.

A very strong ferrite magnetic structure of 25 mm guarantees dynamism and precision and a unique 3,5” inside/outside voice coil design provides a very high-power handling of 1500 Watts RMS of musical power, thanks to its dual forced cooling system guarantees a very efficient voice coil ventilation for minimum power compression.

Product Highlights:

• High BL factor and Xmax for outstanding Low output
• Rated at 1500 watts RMS Continuous Program Power
• 98.5 dB sensitivity, which makes it capable of generating a lot of output!
• 3.5″ Inside/Out CCAW voice coil wound on fiberglass former for hi-temp performance, 8 Ohm

Specifications:

• Nominal Diameter: 12″ (305 mm)

• Nominal impedance: 8 Ohms
• Power Handling:
• Nominal Power Handling: 750 Watts
• Continuous Program Power (RMS): 1500 Watts
• Max Peak Power: 3000 Watts
• Sensitivity 2.83V at 1m:98.5 dB
• Recommended Hi Pass Crossover: 90 Hz

• Frequency Response: 75 – 5,000 Hz
• Voice Coil Diameter: 3.5″ (89 mm)
• Voice Coil Wire: CCAW
• Voice Coil Winding Depth: 17.0 mm
• Former Material: Glass Fiber
• Magnetic Gap Depth: 10.0 mm
• Frame Material: Die Cast Aluminum

Thiele-Small Parameters:

• Equivalent Volume (Vas): 62.37 l

• Excursion (Xmax): 6.00 mm
• Free Air Resonance (Fs): 57.2 Hz
• Mechanical Factor (Qms): 10.87
• Electrical Factor (Qes): 0.37
• Total Factor (Qts): 0.36
• Cone Area (Sd): 585 cm²
• Mechanical Mass (Mms): 59.32 g
• Bl Factor (Bl): 17.27 Tm
• Dc Resistance (Re): 5.2 Ohms
• Inductance (Le): 0.963 mH at 1 kHz
• Mechanical Mass Without Air (Mmd): 51.31 g
• Mechanical Compliance (Cms): 0.130 mm/N

Measurements:

• Overall Diameter: 12.40” (315 mm)
• Front Mount Baffle Cutout: 11.18” (284 mm)
• Mounting Depth: 5.24” (133 mm)
• Overall Depth: 5.87” (149 mm)
• Net Weight: 16.32 lbs (7.4 kg)
• Shipping Weight: 18.08 lbs (8.2 kg)
• Carton Dimensions (W x L x H): 13.19” x 13.19” x 6.90” (335 x 335 x 170 mm)

Note:

• Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.
• Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to avoid a clean signal without clipping or saturation.
• Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.
