Product Highlights:

• Nominal Impedance: 8 Ohm
• Nominal Power Handling: 1000 Watts
• Continuous Program Power (RMS): 2000 Watts
• Sensitivity (1W/1m): 97 dB
• Voice Coil Diameter: 4″

Specifications:

• Nominal Diameter: 12" (305 mm)
• Nominal Impedance: 8Ω
• Power Handling:
• Nominal Power Handling: 1000 Watts
• Continuous Program Power (RMS): 2000 Watts
• Max Peak Power: 4000 Watts
• Sensitivity (1W/1m): 97 dB
• Frequency Range at -10 dB: 60 - 5,000 Hz
• Recommended Hi Pass Crossover: 180 Hz**12dB per Octave Crossover
• Voice Coil Diameter: 4" (101 mm)
• Voice Coil Wire: CCAW
• Voice Coil Winding Depth: 17.0 mm
• Former Material: Aluminum
• Magnetic Gap Depth: 7.5 mm
• Frame Material: Die Cast Aluminum
• Sold Individually

Thiele-Small Parameters

• Equivalent Volume (Vas): 52.52 l
• Excursion (Xmax): 6.62 mm
• Free Air Resonance (Fs): 57.23 Hz
• Mechanical Factor (Qms): 23.84
• Electrical Factor (Qes): 0.34
• Total Factor (Qts): 0.33
• Cone Area (Sd): 573 cm²
• Mechanical Mass (Mms): 67.39 g
• Bl Factor (Bl): 21.25 Tm
• Dc Resistance (Re): 6.3 Ohms
• Inductance (Le): 0.83 mH at 1 kHz
• Mechanical Mass Without Air (Mmd): 59.64 g
• Mechanical Compliance (Cms): 0.114 mm/N

Mounting and Shipping Information:

• Overall Diameter : 12.28" (3.12 mm)
• Front Mount Baffle Cutout: 11.42" (281 mm)
• Mounting Depth: 5.47" (139 mm)
• Overall Depth: 5.91" (150 mm)
• Net Weight: 23.04" Lbs (10.45 kg)
• Shipping Weight: 24.92 Lbs (11.30 kg)

Note:

• Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.
• Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to avoid a clean signal without clipping or saturation.
• Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.
