PRV Audio 12MR2000X v2 12" 2000W RMS Midrange Loudspeaker - 8 Ohm

have questions?

+1 (416) 745-1021

Ask an Expert

Guaranteed Fitment

Always the correct part
In-House Experts

We know our products
Installation Assistance

We're happy to help
Canada Wide Delivery

Free shipping on orders over $200*

PRV Audio

PRV Audio 12MR2000X v2 12" 2000W RMS Midrange Loudspeaker - 8 Ohm

Name: Singh Electronics
Address: 7003 Steeles Avenue West, Toronto, ON, M9W 0A2, CA
Telephone: +1 (416) 745-1021
Price range: $

$384.99

$354.99

SKU:: 12MR2000X V2
Condition:: New
Availability:: Usually Ships In 1-2 Days
Shipping:: Calculated at Checkout

PRV Audio 12MR2000X v2 12" 2000W RMS Midrange Loudspeaker - 8 Ohm

$384.99

$354.99

Description
Shipping & Returns

Description

About: PRV Audio 12MR2000X v2 12" 2000W RMS Midrange Loudspeaker - 8 Ohm (Each)

Built for high efficiency and extreme output capability, the PRV Audio 12MR2000X v2 12” professional midrange driver is perfect for filling in the midbass and vocal range in the largest SPL systems. This powerful driver features a thoroughly vented 4” diameter voice coil on a heat resistant Kapton former to handle 2,000 watts RMS with minimal power compression. X Series is dedicated to delivering extreme midrange performance, capable of high output and high power handling, while delivering a smooth vocal response.

Extreme car audio enthusiasts will find PRV Audio’s 12MR2000X to be the perfect 12″ midrange door speaker. It is capable of handling up to 2000 watts RMS power (with a suggested 150 Hz, 18 dB/octave high pass filter in place tuned with PRV DSP)! The large magnet assembly is attached to a sturdy, reinforced cast-aluminum frame.

A Qts of 0.28 and a double roll suspension design allow for a strong response from 400Hz to 300Hz, even at high excursion controlling well its natural paper cone at its 6.60 mm Xmax. Its composite cone is built with non-pressed paper (visible on the back side) for reduced break-up and smooth sound. The high power handling, combined with 100 dB sensitivity, allows this mid to produce incredible dynamics and low distortion when pushed to incredible output levels.

Features:

2,000 Watts RMS with 100 dB efficiency for amazing output capability
6.60 mm xmax allows excellent control to deliver high impact midbass
Detailed vocal reproduction, high fidelity response
Excellent performance in compact enclosures
Extensive venting keeps the 4” voice coil cool improving reliability when pushed to the limit

Specifications:

Nominal Diameter: 12″ (305 mm)
Nominal impedance: 8 Ohm
Nominal Power Handling: 1000 Watts
Continuous Program Power (RMS): 2000 Watts
Max Peak Power: 4000 Watts
Sensitivity 2.83V at 1m: 100 dB
Recommended Hi Pass Crossover (For Full Power Handling): 160 Hz **12db Per Octave Crossover
Frequency Response at -10dB: 100 – 5,300 Hz
Voice Coil Diameter: 4″ (100 mm)
Voice Coil Wire: CCAW
Voice Coil Winding Depth: 18.2 mm
Former Material: Glass Fiber
Magnetic Gap Depth: 10.00 mm
Frame Material: Die cast aluminum
Sold Individually

Thiele-Small Parameters:

Equivalent Volume (Vas): 39.61 l
Excursion (mathematical) (Xmax): 6.60 mm
Free Air Resonance (Fs): 64.7 Hz
Mechanical Factor (Qms): 17.19
Electrical Factor (Qes): 0.28
Total Factor (Qts): 0.28
Cone Area (Sd): 573 cm²
Mechanical Mass (Mms): 69.86 g
Bl Factor (Bl): 23.19 Tm
Dc Resistance (Re): 5.4 Ohm
Inductance (Le): 0.43 mH at 1 kHz
Mechanical Mass Without Air (Mmd): 62.11 g
Mechanical Compliance (Cms): 0.086 mm/N

Mounting and Shipping Information:

Overall Diameter: 12.28″ (312 mm)
Front Mount Baffle Cutout: 11.14” (283 mm)
Mounting Depth: 4.48″ (114 mm)
Overall Depth: 4.96″ (126 mm)
Net Weight: 26.65 Lbs (12.08 kg)
Shipping Weight: 28.15 Lbs (12.76 kg)
Carton Dimensions (W x L x H): 13.38″ x 13.38″ x 6.29″ (340 x 340 x 160 mm)

Note:

Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.
Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to avoid a clean signal without clipping or saturation.
Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.
