About: PRV Audio 8MR600-NDY 8" 300W RMS Neodymium Midrange Woofer - 8 Ohm (Each)

The PRV Audio Pro Audio Loudspeaker, 8MR600-NDY midrange woofer offers outstanding durability and a smooth midrange response through 11kHz. This woofer is perfect for home Hi-Fi installs, including bookshelf, satellite, surround sound speakers and even the home studio monitors. It is a great option for three way cabinets requiring additional midrange support.

The high end neodymium magnet assembly was chosen to increase sensitivity and power handling. This neodymium is attached to a sturdy reinforced cast aluminum frame to ensure a solid support structure for long lasting play in most any environment. Its light weight of only 4 lbs helps keep your enclosures light and is a great use for use for car doors and installers looking for high SPL midrange and upper midrange responses.

Features:

• 2" Voice Coil
• 300 Watts Continuous Power Handling
• 96 dB Sensitivity
• Light Weight Neodymium Magnet

Specifications:

• Nominal Diameter: 8" (203.2 mm)
• Nominal Impedance: 8 Ohms
• RMS Power: 300 Watts
• Musical Program Power: 600 Watts
• Sensitivity: 96dB
• Frequency Response: 75-11,000 Hz
• Voice Coil Diameter: 2" (50 mm)
• Voice Coil Material: CCAW
• Voice Coil Former Material: Kapton
• Sold Individually

Thiele-Small Parameters:

• Equivalent Volume (Vas): 12.5 l
• Excursion (Xmax): 3 mm
• Free Air Resonance (Fs): 78.06 Hz
• Mechanical Factor (Qms): 4.772
• Electrical Factor (Qes): 0.606
• Total Factor (Qts): 0.537
• Cone Area (Sd): 212.9 cm²
• Mechanical Mass (Mms): 21.41 g
• Bl Factor (Bl): 10.43 Tm
• Dc Resistance (Re): 6.28 Ohms

Mounting and Shipping Information:

• Overall Diameter: 8.75” (222 mm)
• Front Mount Baffle Cutout: 7.9” (201 mm)
• Mounting Depth: 3.2” (81.7 mm)
• Overall Depth: 3.4” (87.9 mm)
• Weight: 4.02 Lbs (1.82 kg)
