PRV Audio WG14-50CR 2" Aluminum Waveguide

$48.99

$41.99

Description
Shipping & Returns

Description

About: PPRV Audio WG14-50CR 2" Aluminum Waveguide

PRV Audio’s WG 14-50CR 45° x 45° exponential horn is designed to project a controlled dispersion pattern, such as needed with personal stage monitors, over a long distance. Strong, lightweight aluminum construction is used to keep cabinets as light as possible for easy transport while supporting the weight of the compression driver. A standard 4-bolt flange is compatible with many 2″ compression drivers. Acoustic loading is maintained down to 600 Hz.

Product Highlights:

Horn type: Exponential
Minimum frequency: 600 Hz
Nominal dispersion: 45° H x 45° V
Throat diameter: 2″
Mounting type: 4-bolt
Overall front Size: 6.93″ x 6.16″
Baffle cutout: 5.39″ Diameter Circle
Mounting Depth: 4.64

Specifications:

Throat Diameter: 2" (50.8 mm)
Mounting Type: Bolt-On

Hole Dimensions: 0.24" (8 mm)
Bolt Circle: 4" (102 mm)

Nominal Coverage

Horizontal: 45°
Vertical: 45°

Flare Type: Exponential
Material: Aluminum
Finish/ Coating: Black
Dimensions:

Height: 6.93" (176 mm)
Width: 6.16" (156.5 mm)
Depth: 5.02" (127.6 mm)
Mount Depth: 4.64" (118 mm)

Baffle Cutout

Diameter Circle: 5.39" (137 mm)

Sound Dispersion Hxv: 45° X 45°
Weight: 1.5 Lbs (0.67 kg)
Sold Individually
