About: Rockford Fosgate Punch PP4-X Passive Crossover

The PP4-X is designed for use with 4-Ohm Punch Pro midrange drivers and tweeters. It features dual woofer outputs for use with two Punch Pro midrange drivers. Provides 6dB/Octave dedicated low pass filter for the woofer.

Must use existing built-in 6dB/Octave Punch Pro crossover supplied with tweeter. Designed ONLY for Rockford Fosgate Punch Pro speakers (not designed to be used as a stand-alone passive crossover for other "pro" brands). Mounting hardware included. The PP4-X is designed for use with 4-Ohm Punch Pro midrange drivers and tweeters. Sold individually (1 each).

Features:

• Designed for use with Punch Pro midrange drivers and tweeters
• 125 Watts RMS (250 Watts MAX) power handling
• Must use 4-Ohm load on woofer outputs
• Dual woofer outputs for use with two Punch Pro midrange
• Provides 6dB/Octave, 3kHz low pass for woofer
• Selectable tweeter impedance: 4-Ohm or 8-Ohm
• Selectable tweeter attenuation: 0dB, -3dB, -6dB
• Mounting hardware included
• Works with built-in 6dB/Octave Punch Pro tweeter crossover
• Sold individually (1 each)

Specifications:

• Single passive crossover for Rockfod Fosgate Punch Pro Series components
• Works with 4-ohm Punch Pro midrange speakers only
• Works with a PP4-T or a PP8-T Punch Pro tweeter
• Low-pass filter for woofer (3K Hz, 6 dB/octave)
• Power rating: 125 watts RMS (250 watts max)
• Dual woofer outputs for use with two speakers
• Selectable tweeter impedance (2 or 4 ohms)
• Selectable tweeter level (0, -3, or -6 dB)
• Mounting hardware included

What's in the Box:

• One passive crossover
• Four 1-3/4" Self-tapping Allen head screws
• 3mm Allen head bit
• Instructions
