SounDigital 5000.1EVOX2 5000W RMS Class D Monoblock Amplifier

Name: Singh Electronics
Address: 7003 Steeles Avenue West, Toronto, ON, M9W 0A2, CA
Telephone: +1 (416) 745-1021
Price range: $

$1,999.99

SKU:: 5000.1EVOX2
Condition:: New
Availability:: Special Order - Usually Ships in 4-8 Days
Shipping:: Calculated at Checkout

SounDigital 5000.1EVOX2 5000W RMS Class D Monoblock Amplifier

$1,999.99

Description
Shipping & Returns

Description

About: SounDigital 5000.1EVOX2 5000W RMS Class D Monoblock Amplifier

The 5000.1 EVOX2 is a compact, modern amplifier that delivers 5000W RMS of power over 1 channel.

The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects.

Specifications:

5000.1 EVOX2 – 1 OHM:

Power @ 4Ω: 1 X 2178W RMS
Power @ 2Ω: 1 X 3300W RMS
Power @ 1Ω: 1 X 5000W RMS

5000.1 EVOX2 – 2 OHMS:

Power @ 1Ω: N/A
Power @ 2Ω: 1 X 5000W RMS
Power @ 4Ω: 1 X 3300W RMS

Frequency Response (-3dB): 5Hz ~ 6kHz
Subsonic Filter (12dB/oct.): 5Hz ~ 40Hz
Low Pass Filter (12dB/oct.): 50Hz ~ 6kHz
Bass Boost:0dB ~ 12dB @ 50Hz
Operating Voltage: 8V ~ 16V
SNR: 99dB
Input Sensitivity (RCA): 0.2V ~ 2V
Input Sensitivity (High Level input): 1.5V ~ 15V
Current Draw (music): 200A
Current Draw (max.): 400A
Total Efficiency:90 %
Damping Factor (@100Hz nominal impedance): >3000
Power Cable: 70mm² / 0AWG
Speaker Cable:16mm² (5AWG)
Recommended Fuse* (music): 2 x 150A
Recommended Battery (minimum): 2 x 135Ah
Dimensions (W x L x H): 7.1" x 9.8" x 2.5" (18 x 25 x 6.3 cm)
Weight: 2.7 kg / 6.0 lb
