About: Stetsom Bravo Full 5000 Digital 5K Full-Range Mono Amplifier
The BRAVO FULL line was developed for automotive sound lovers who seek maximum performance in FULL-RANGE amplifiers. Its frequency response from 10Hz to 12kHz offers audio quality and definition, and can be used with subwoofers, woofers, drivers, and tweeters.
Specifications:
BRAVO FULL 5000 – 1 Ohm | BRAVO FULL 5000 – 2 Ohms | |
Number of Channels | 1 | 1 |
RMS Power | 5000W RMS | 5000W RMS |
RMS Power at 1 Ohm 12.6V | 5000W RMS | |
RMS Power at 2 Ohm 12.6V | 2800W RMS | 5000W RMS |
RMS Power at 4 Ohm 12.6V | 2600W RMS | |
RMS Power at 1 Ohm 14.4V | 5300W RMS | |
RMS Power at 2 Ohm 14.4V | 5300W RMS | 5300W RMS |
RMS Power at 4 Ohm 14.4V | 3000W RMS | |
Supply Voltage | 9V ~ 16V DC | 9V ~ 16V DC |
Frequency Response | 10Hz ~ 12KHz | 10Hz ~ 12KHz |
Crossover Low Pass | 90Hz ~ 12KHz | 90Hz ~ 12KHz |
Crossover High Pass | 10Hz ~ 90KHz | 10Hz ~ 90Hz |
Signal to Noise | >90dB | >90db |
Input Sensitivity | 200mV | 200mV |
Input Impedance | 12K Ohms | 12K Ohms |
Impedance Output | 1 Ohm | 2 Ohms |
Consumption with Signal Musical | 242A | 227A |
Consumption with Signal Bass | 485A | 445A |
Dimensions (H x W x D) | 80 x 231.5 x 333 mm | 80 x 231.5 x 333 mm |
Weight | 4.25 Kg | 4.25 Kg |
