About: Sundown Audio U-6.5 U-Series 6.5" 400W RMS Car Subwoofer
Perfect for high-power underseat enclosures and designed to be at home in the competition lanes or playing your favorite tunes, the U Series is the premier “standard suspension” woofer in the Sundown lineup. A double-stacked 9” wide ferrite magnet system is coupled to a thick top plate. A thick set of shorting rings are also used inside the magnets and on the pole cap, smoothing out frequency response while doubling as a heat sink and airflow guide. An all-new, substantially thicker custom aluminum frame was designed specifically for the U Series, and equipped with heat-dissipation ribs. The v.2 motor also features an extended pole piece to keep the coil controlled under high stress!
Specifications:
Enclosure Specifications:
| Thiele-Small Parameters | U-6.5SW" D2 | U-6.5SW" D4 |
|---|---|---|
| Dc Resistance (Re) | 4.0586 Ohms | 6.6274 Ohms |
| Resonance Frequency (Fs) | 41.9533 Hz | 38.6925 Hz |
| Equivalent Volume (Vas) | 2.9053 L | 3.7701 L |
| Electrical Factor (Qes) | 0.5238 | 0.5005 |
| Mechanical Factor (Qms) | 8.5834 | 7.2470 |
| Total Factor (Qts) | 0.4937 | 0.4681 |
| Inductance (Le) | 4.0112 mH | 5.5892 mH |
| Bl Factor (BL) | 16.7428 | 20.0082 |
| Mechanical Mass (Mms) | 137.2546 g | 124.3518 g |
| Mechanical Compliance (Cms) | 104.8528 uM/N | 136.0613 uM/N |
| Sens (dB @ 1w/1m) | 77.8706 | 78.1460 |
