About: Taramps MD5000.1 5000W RMS Class D Monoblock Car Amplifier (Taramp's Authorized Canadian Dealer)
Unleash the power of clarity and performance with the Taramps MD 5000.1, a high-efficiency full-range monoblock amplifier that delivers up to 5000 Watts RMS at 1 Ohm. Engineered for versatility, it’s ideal for subwoofers, mid-bass, mid-range, and full-range speakers in a wide variety of car audio systems.
Operating within a wide frequency response from 10Hz to 10kHz, the MD 5000.1 guarantees excellent reproduction of lows, mids, and highs with precision. It offers flexible tuning tools such as variable high-pass and low-pass crossovers, Bass Boost control, and input sensitivity of 220mV, allowing perfect integration and sound customization.
Built with advanced protection features—including short circuit, thermal, low impedance, and voltage protection—the MD 5000.1 ensures reliable operation even under demanding conditions, it optimizes energy use without sacrificing performance.
Its rugged construction includes a compact aluminum chassis and smart design layout, making it easy to install even in tight spaces. Whether you’re going for SPL, sound quality, or everyday reliability, the Taramps MD 5000.1 is ready to deliver.
Technical Information:
| |
1 Ohm Version |
2 Ohms Version
|
| Maximum Power |
Nominal Power @12,6VDC 1 Ohm: 5000W RMS 2 Ohms: 3200W RMS 4 Ohms: N/A |
Nominal Power @12,6VDC 1 Ohm: N/A 2 Ohms: 5000W RMS 4 Ohms: 3200W RMS
|
| Number of Channels |
01 |
01 |
| Input Sensitivity |
220mV |
220mV |
| Signal to Noise Ratio |
>90dB |
>90dB |
| Frequency Response |
10Hz ~ 10KHz (-3dB) |
10Hz ~ 10KHz (-3dB) |
| Crossover High Pass (HPF) |
10Hz ~ 90Hz (-12dB/8ª) Variable |
10Hz ~ 90Hz (-12dB/8ª) Variable |
| Crossover Low Pass (LPF) |
90Hz ~ 10KHz (-12dB/8ª) Variable |
90Hz ~ 10KHz (-12dB/8ª) Variable |
| Bass Boost |
Freq.: 35Hz ~ 55Hz Boost: 0 ~10dB (50Hz) |
Freq.: 35Hz ~ 55Hz Boost: 0 ~10dB (50Hz) |
| Efficiency |
81% |
86% |
| Input Impedance |
15K Ohms |
15K Ohms |
| Output Impedance |
1 Ohm |
2 Ohms |
| Protection System |
Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection. |
Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection. |
| Minimum Supply Voltage |
9VDC |
9VDC |
| Maximum Supply Voltage |
16VDC |
16VDC |
| Consumption at rest |
1.20A |
1.40A |
| Maximum Music Consumption |
244.50A |
230.50A |
| Maximum Consumption in Sinusoidal Signal |
489A |
461A |
| Dimensions (W x H x D) |
8.98" x 2.76" x 12.87" (228 x 70 x 327mm) |
8.98" x 2.76" x 12.87" (228 x 70 x 327mm) |
| Weight |
9.28lb (4.22Kg) |
9.28lb (4.22Kg) |
| EAN |
7898556844697 |
7898556844499 |
Precautions:
- Do not mount amplifier to speaker box. Cyclic Vibrational Failure is #1 fail rate of amplifiers and these are lighter than most so their potential is higher if not followed.
- Do not wire this amplifier lower than 1 ohm nominal Impedance. (Equivalent to ~0.7 ohms DCR or Resistive measurement via DMM).
- Do not clip amplifier above 15.0v for extended periods of time
- Do not drive amplifier into clipping + protection for extended periods of time (exceeding 20% THD)
