About: Yorkville VGM14 EPM6 14-Channel Audio Mixer with Effects and USB
The VGM14 is a compact analog mixer with onboard effects that builds on the PGM8 by offering more channels, more features, and a built-in 2-channel USB audio interface. It’s an all-in-one solution for live sound, installations, and presentations that require up to fourteen input channels (ten mono, two stereo).
It offers extended connectivity with twelve XLR mic inputs, ten mono 1/4" inputs, and two stereo 1/4" inputs. Hi-Z switches on channels 9 and 10 enable the direct connection of instrument-level signals such as a guitar or bass without requiring an external DI. Each channel has a switchable high-pass filter, mute and solo buttons, clip indicator, and 60 mm fader. Mono channels feature a 3-band EQ with a sweepable midrange frequency, and stereo channels feature 4-band EQ.
The 24-bit DSP engine has sixteen stereo effects including reverb, delay, modulation, and more. Channels 1 through 10 offer built-in compression and insert points, and a 9-band graphic EQ on the main output lets you fine-tune the total mix.
The VGM14 also includes multi-segment VU metering, phantom power, RCA connections to easily integrate consumer AV equipment, footswitch support to mute the onboard effects, a convenient global mute for input channels, a dedicated zone / subwoofer output, LED lamp connector, and independent control of main, monitor, and headphone levels.
Packed with features and intuitive to operate, we like to think the VGM14 is a very good mixer.
Features:
- 10x Mono Channels (XLR / 1/4")
- 2x Stereo Channels (1x XLR, 2x 1/4")
- Global Phantom Power
- Selectable Hi-Z Instrument Input on Channels 9 and 10
- Onboard Compression on Channels 1 - 10
- Onboard Digital Effects with 16 Algorithms and Parameter Control
- 3-Band EQ per Channel with 9-Band Master Graphic EQ
- 60 mm Faders
- 2-Channel USB Audio Interface
Specifications:
- Number of Channels: 14
- Channel Inserts: 10
- Channel EQ:
- 3-Band with Mid Sweep (Mono Channels)
- 4-Band (Stereo Channels)
- Channel Overload Protection Yes
- Inputs
- 12x XLR
- 14x 1/4" TRS
- 1x Stereo RCA
- Channel Features
- Gain, High-Pass Filter (80 Hz)
- Monitor Send
- Pre / Post Aux Send
- EFX Send
- Pan / Balance
- Mute
- Solo
- Clip / Mute LED
- Phantom Power: Global 48 V with LED Indicator
- VU Meter 2x 10-Segment LED
- Headphone Monitor Features: 1x 1/4"
- Internal Effects: 16 Algorithms, 24-Bit Stereo with Parameter Control
- Auxiliary Sends:
- EFX (to Internal Effects and 1/4" EFX Send)
- Aux (to 1/4" Aux Send)
- Outputs:
- 1x RCA (Record Out)
- 1x USB (Media Out)
- 2x 1/4" TRS (Main Outs)
- 2x XLR (Main Outs)
- 1x 1/4" (Zone/Sub Out)
- Master EQ -1 (type/Channels/Range -dB): 9-Band Graphic
- Mixer - Frequency Response: 20 Hz - 20 kHz
- Mixer THD (Main out w/ -10dB input): <0.05%
- CMRR AT 60Hz (min/typ): 55 dB / 65 dB
- Power Consumption (typ/max): 26 VA
- Cooling: Fan
- Transformer Type: SMPS
- Chassis Construction: Steel
- Console Lamp Connector: 12V DC (BNC) 12V DC (BNC)
- Other Features:
- Input Compressors (Channels 1 - 10)
- Hi-Z Input Switch (Channels 9 - 10)
- EFX Footswitch Jack
- Zone / Sub Output
- USB I/O
- Dimensions (DWH inches): 16" x 19" x 2.8" (40.6 cm x 48.3 cm x 7.1 cm)
- Weight (lbs/kg): 13 lbs / 5.9 kg
