About: DS18 HOOL-X12.4DHE 12" 4000W RMS High Excursion Car Subwoofer – DVC 4-Ohm

Experience a new level of bass performance and power with DS18’s HOOL-X12.4DHE! The HOOLIGAN 12” High Excursion Car Subwoofer has been the top choice for enthusiasts and competitors alike, and now, it’s back with a vengeance.
The HOOLIGAN is built for power and durability. The redesigned long throw pole, larger spider, and high excursion surround, helps lower the HOOLIGAN’s FS (Resonant Frequency), making it even louder at subsonic frequencies. With an FS of 26, this subwoofer guarantees impressive low frequencies all the way down to 20Hz. Its high-powered 4" Black Aluminum voice coil can handle 4000W RMS and 6000W MAX power, making it perfect for heavy-hitting competition bass.
Versatility is key, and the HOOL-X12.4DHE can adapt to various enclosure types. Whether you prefer 4th orders, 6th orders, ported boxes, or large sealed boxes, this subwoofer will thrive in any setup that has enough room.
This version of the HOOLIGAN boasts a nominal diameter of 12" (304.8 mm) and a nominal impedance of 4+4 OHMS to amplify the performance and capabilities of this high-powered subwoofer. With a sensitivity of 87 dB and a frequency response ranging from 20Hz to 500Hz, this subwoofer ensures every beat is reproduced with staggering depth and precision.
DS18’s HOOLIGAN 12" High Excursion Car Subwoofer is the ultimate choice for car audio enthusiasts seeking extreme bass and massive power. Its unmatched performance, cutting-edge design, and versatility make it a must-have for any ground shaking audio system.

Features:

• 12" High Excursion Subwoofer
• MAX Power: 6000 Watts
• RMS Power: 4000 Watts
• Impedance: 4-Ohm 4" DVC
• Ferrite Magnet
• 87dB

Specifications

• Sku: HOOL-X12.4DHE
• Nominal diameter: 12" / 304.8mm
• Nominal impedance: 4+4 ohms
• Rms power handling: 4000W
• Max power handling: 6000W
• Sensitivity (1w/1m): 87dB
• Frequency response: 20-500Hz
• Recommended lo pass crossover: 80Hz

Motor

• Voice coil diameter: 4” / 99.8mm
• Voice coil former material: Black aluminum
• Winding material: CCAW
• Cone material: Non-pressed paper
• Dust cap material: Carbon fiber
• Surround material: Foam
• Basket material: Aluminum
• Basket color/finish: Gloss black with machined aluminum
• Magnet material: Ferrite
• Magnet weight: 500 OZ
• Displacement volume: 4.8L / 0.169ft3

Thiele & small parameters

• Equivalent volume: 21.86L / 0.77ft3
• Free air resonance: 26Hz
• Mechanical factor: 2.75
• Electrical factor: 0.528
• Total factor: 0.517
• Moving mass: 486.45g
• Compliance: 0.074mm/N
• Bl factor: 23.86
• Voice coil inductance: 42.15mH
• Diaphragm area: 471.44cm2
• Dc resistance: 3.2+3.2 ohms
• Efficiency bandwidth product: 49.2

Recommended enclosures

• Sealed internal volume: 17L / 0.6ft3
• Sealed box output response: 41Hz
• Ported internal volume: 42.5L / 1.5ft3
• Port size (square w x h x long): 1.52" x 12.28" x 31.82" / 38.5 x 312 x 808.2 mm
• Port tunning frequency: 30Hz
• Ported box output response: 25Hz

Measurement

• Overall diameter: 12.64" / 321mm
• Overall depth: 11.6" / 295mm
• Front mount baffle cutout: 11.2" / 285mm
• Mounting depth: 10" / 255mm
• Motor diameter: 9.96” / 253mm
• Product weight (lb): 87.5
• Dimensions l x w x h (inches): 15 x 15 x 14
• M/c weight (lb): 87.5
• M/c dimensions l x w x h (inches): 15 x 15 x 14
• M/c qty: 1
• Sold in: Single
