About: DS18 SXE-3000.4D/RD Class D 4-Channel Full-Range Car Amplifier
DS18’s SXE Amplifier Series was designed for enthusiasts looking for an extreme increase to the quality of audio reproduced by their vehicle. With the SXE-3000.4D at the helm, your vehicle's speakers will unleash their true potential, effortlessly detailing the best parts of your favorite tracks.
The SXE-3000.4D offers you the ability to shape your systems audio to match your personal preferences. Its fully variable crossover, adjustable gain input sensitivity, and multi-channel amplifier design allows you to fine-tune your audio, ensuring every beat, melody, and lyric is reproduced with astonishing accuracy. The compact size of the SXE-3000.4D enables easy installation anywhere in your vehicle, making it a versatile companion for your custom audio setup. Immerse yourself in a customized soundstage that complements your unique style.
Thanks to its Class D circuit design the SXE-3000.4D seamlessly integrates into any vehicle's custom build, without compromising on its power. Prepare to be blown away by the SXE-3000.4D's staggering performance, delivering 500W x 2 CH bridged at 4-ohms, 320W x 4 CH at 2-ohms, and 200W x 4 CH at 4-ohms. These power settings are guaranteed to supercharge any custom build, leaving you with a smile that stretches from ear to ear.
The SXE-3000.4D also comes equipped with various forms of electronic protection, including thermal protection that shields against overheating, over-load protection, and short circuit output protection. Additionally, the 80℃ thermal protection ensures the amplifier operates optimally, even in demanding conditions. DS18 has thought of everything to guarantee a long-lasting and exceptional audio experience.
Product Highlights:
- Full Range Amplifier
- 4 Channel
- Class D
- 2 ~ 4 Ohm Stable
- 4 x 200 Watts @ 4 Ohm
- Compact Design
Specifications:
- Class: Digital
- Amplifier Type: Stereo Full Range
- Channels: 4 CH
- Peak Power: 3000W
- RMS Power @ 4 Ohm/14.4V: 4 x 200W
- RMS Power @ 2 Ohm/14.4V: 4 x 320W
- RMS Power @ 4 Ohm/14.4V Bridged: 2 x 500W
- Minimum Impedance: 2 Ohm Stereo / 4 Ohm Bridge
- Operation Voltage: 10 - 15V
- Frequency Response: 10Hz-20KHz
- Signal/Noise Ratio: 90dB
- Low Pass Filter: 40Hz - 400Hz
- High Pass Filter: 40Hz - 400Hz
- Subsonic: NO
- Subsonic Frequency: N/A
- Efficiency @ 4 Ohm: 88%
- Damping Factor: 140
- THD %: 0.05%
- Input Sensitivity: 0.2V - 6V
- X-Over Filter Range: 40HZ-2KHZ
- Bass Boost Range: NO
- Bass Boost Frequency: N/A
- Phase Selector: NO
- High Level Input: NO
- Selectable X-Over: HPF/FULL/LPF
- Led Indicator: Power/Protect/Clip
- Voltage Input Protection: Yes (16.5v)
- Clipping Protection: Yes
- Thermal Protection: Yes
- Speaker Output Size: 12GA
- Power Input Size: 4GA
- Fuse Rating: 40A x 2
- Remote Level Control: NO
- Body Color / Finish: Red Brushed Aluminum
- Product Weight: 4lb
- Product Dimensions (L x W x H): 11.75" x 7.75" x 3.25"
