Taramps MD 8000.1 High Power Car Amplifier

Name: Singh Electronics
Address: 7003 Steeles Avenue West, Toronto, ON, M9W 0A2, CA
Telephone: +1 (416) 745-1021
Price range: $

$679.99

$659.99

SKU:: MD8000
UPC:: 7898556844468
Condition:: New
Availability:: Usually Ships in 1-2 Days
Shipping:: Calculated at Checkout

Taramps MD 8000.1 High Power Car Amplifier

$679.99

$659.99

Description
Shipping & Returns

Description

About: Taramps MD 8000.1 High Power Car Amplifier (Taramps Authorized Canadian Dealer)

The MD 8000.1 amplifier is carefully developed with state-of-the-art technology, offering unique efficiency and performance for automotive audio systems. Classified as Mono, it has a maximum power of 8.000 watts RMS, running at a 1-ohm or 2-ohm impedance, with a single 8,000 watts RMS channel. This amplifier is FULL-RANGE, operating on all frequencies in the right measure. It is an amplifier classified as mono, has a channel with a maximum power of 8000 Watts RMS. Welcome to the sound world of Taramps.

Technical Information:

	MD 8000.1 – 1 OHM	MD 8000.1 – 2 OHMS
OPERATION CLASS	Class D	Class D
NUMBER OF CHANNELS	01	01
MAXIMUM POWER	@ 12,6 VDC - 1 OHM: 8000W RMS @ 12,6 VDC - 2 OHMS: 5120W RMS	@ 12,6 VDC - 2 OHMS: 8000W RMS @ 12,6 VDC - 4 OHMS: 4800W RMS
INPUT SENSITIVITY	0.22V ~ 4V	0.22V ~ 4V
SIGNAL TO NOISE RATIO	>90dB	>90dB
FREQUENCY RESPONSE	10Hz ~ 8KHz (-3dB)	10Hz ~ 8KHz (-3dB)
CROSSOVER HIGH PASS (HPF)	10Hz ~ 90Hz(-12/8ª) Variable	10Hz ~ 90Hz (-12dB/8ª) Variable
CROSSOVER LOW PASS (LPF)	90Hz ~ 10KHz (-12dB/8ª) Variable	90Hz ~ 10KHz (-12dB/8ª) Variable
BASS BOOST	Freq: 35Hz to 55Hz Boost: 0 ~ 10dB (50Hz)	Freq.: 35Hz ~ 55Hz Boost: 0 ~10dB
EFFICIENCY	82%	85%
INPUT IMPEDANCE	10K Ohms	10K Ohms
OUTPUT IMPEDANCE	1 Ohm	2 Ohms
PROTECTION SYSTEM	Short-Circuit to Output, short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection	Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection.
MIN. SUPPLY VOLTAGE	9.5VDC	9.5VDC
MAXIMUM POWER SUPPLY VOLTAGE	17VDC	17VDC
CONSUMPTION AT REST	2.90A	2.90A
MAXIMUM MUSIC CONSUMPTION	387A	374A
MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL	774A	748A
DIMENSIONS (H X W X D)	8.98" x 2.76" x 17.5" (228 x 70 x 446 mm)	8.98" x 2.76" x 17.5" (228 x 70 x 446 mm)
WEIGHT	12.34lb (5.60Kg)	12.34lb (5.60Kg)
EAN	7898556844468	7898556848893

Precautions:

Do not mount amplifier to speaker box. Cyclic Vibrational Failure is #1 fail rate of amplifiers and these are lighter than most so their potential is higher if not followed.
Do not wire this amplifier lower than 1ohm nominal Impedance. (Equivalent to ~0.7 ohms DCR or Resistive measurement via DMM).
Do not clip amplifier above 15.0v for extended periods of time
Do not drive amplifier into clipping + protection for extended periods of time (exceeding 20% THD)
